Self Aligning Ball Bearings 1213-K C/4

Brand: TFL Bearing Interchangeable: SKF 1213-K C/4 65 mm × 120 mm × 23 mm Metric Open
Part number: 1213-K C/4
Self Aligning Ball Bearings 1213-K C/4
In Stock
US$56.75 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia120 mm
Outer Dia Tolerance-0.015mm to 0
Width23 mm
Width Tolerance-0.15mm to 0
External Diameter On Inner Ring85.1 mm
Internal Diameter On Outer Ring104 mm
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load7,898 lbf
Static Radial Load3,150 lbf
Temperature Range-30° to 110 °C
Max Speed7,000 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
Bore TypeTaper 1:12
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Radial ClearanceCN
Weight1.1 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1213-K C/4 is a self-aligning ball bearing with a 65mm tapered bore and 120mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 7898 lbf and operates smoothly at speeds reaching 7000 RPM.

Its double-row design and open construction allow for easy lubrication and alignment adjustments, while the nylon cage reduces friction. The bearing performs reliably in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for machinery with misalignment issues, such as conveyor systems or agricultural equipment.

Weighing 1.1kg, it’s a robust choice for heavy-duty applications. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

How Does 1213-K C/4 Bearing Ensure Smooth Radial Load Handling?

1213-K C/4 Bearing features a double-row design with chrome steel rings and balls, optimised for radial load distribution.
Its dynamic radial load capacity of 7898 lbf ensures reliable performance in various applications.
The nylon cage maintains ball alignment, reducing friction and noise during operation.
With a maximum speed of 7,000 rpm, it offers a balance of durability and efficiency.

Application

Industrial Uses of 1213-K C/4 Bearing
1213-K C/4 Bearing is commonly used in conveyor systems and material handling equipment, where its self-aligning feature compensates for minor misalignments. The double-row design ensures reliable performance under radial loads in demanding environments.

Where Is 1213-K C/4 Bearing Used?
You’ll often find 1213-K C/4 Bearing in agricultural machinery, such as grain augers and harvesters, where its tapered bore provides a secure fit. The nylon cage reduces friction, making it suitable for moderate-speed applications.

Built for Heavy-Duty Use: 1213-K C/4 Bearing
1213-K C/4 Bearing handles radial loads effectively in construction equipment like compactors and mixers. Its chrome steel construction offers durability, while the lubricated design ensures smooth operation over time.

Automotive vs Aerospace: Applications of 1213-K C/4 Bearing
In automotive applications, 1213-K C/4 Bearing supports components like drive shafts and wheel hubs. For aerospace, its precision and reliability make it useful in auxiliary systems where alignment is critical.

Perfect Fit for Automation: 1213-K C/4 Bearing
1213-K C/4 Bearing works well in robotic arms and automated assembly lines, thanks to its self-aligning capability. The metric sizing ensures compatibility with a wide range of industrial machinery.
