Self Aligning Ball Bearings 1213 EKTN9/C3W64

Self Aligning Ball Bearings 1213 EKTN9/C3W64

The 1213 EKTN9/C3W64 is a self-aligning ball bearing with a 65mm bore and 120mm outer diameter, designed for radial loads. Its double-row construction and chrome steel components ensure durability, handling up to 7898 lbf dynamic load.

The tapered bore (1:12) allows for secure mounting, while the open design and nylon cage enable smooth operation at speeds up to 7000 RPM. It comes pre-lubricated for easy installation and maintenance.

With a C3 radial clearance, this bearing accommodates slight misalignments, making it suitable for applications like conveyor systems or agricultural machinery. It performs reliably in temperatures from -30°C to 110°C.

Weighing 1.1kg, it’s a sturdy yet manageable choice for industrial use. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for hassle-free replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1213 EKTN9/C3W64
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 120 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 23 mm
  • Width Tolerance -0.15mm to 0
  • External Diameter On Inner Ring 85.1 mm
  • Internal Diameter On Outer Ring 104 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 7898 lbf
  • Static Radial Load 3150 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 1.1 kg
Self Aligning Ball Bearings 1213 EKTN9/C3W64 dimension drawing
Download DWG Download PDF

Features

How Does 1213 EKTN9/C3W64 Bearing Reduce Friction?

1213 EKTN9/C3W64 Bearing features a double-row design with chrome steel rings and balls, ensuring smooth radial load distribution.
The nylon cage minimises friction, allowing for quieter operation and reduced energy consumption.
With a dynamic radial load capacity of 7898 lbf, it handles demanding applications effortlessly.
Its C3 radial clearance provides optimal performance in various operating conditions.

Application

Common Applications of 1213 EKTN9/C3W64 Bearing
In industrial settings, 1213 EKTN9/C3W64 Bearing is a go-to for conveyor systems and pumps, thanks to its self-aligning feature that compensates for minor misalignments. The double-row design ensures it can handle higher radial loads with ease.

Where Is 1213 EKTN9/C3W64 Bearing Used?
You’ll often spot 1213 EKTN9/C3W64 Bearing in automotive transmissions, where its tapered bore provides a secure fit. The nylon cage reduces friction, making it ideal for high-speed applications.

Built for Heavy-Duty Use: 1213 EKTN9/C3W64 Bearing
This bearing shines in construction equipment, where its chrome steel construction withstands tough conditions. The C3 radial clearance allows for thermal expansion, ensuring reliable performance.

Automotive vs Industrial: Applications of 1213 EKTN9/C3W64 Bearing
In cars, 1213 EKTN9/C3W64 Bearing supports smooth gear shifts, while in factories, it keeps heavy machinery running smoothly. Its versatility makes it a favourite across sectors.

Perfect Fit for Automation: 1213 EKTN9/C3W64 Bearing
Robotic arms benefit from 1213 EKTN9/C3W64 Bearing’s ability to handle misalignment and radial loads. The lubricated design ensures long service life with minimal maintenance.
