Self Aligning Ball Bearings 1207 EKTN9/C3

Self Aligning Ball Bearings 1207 EKTN9/C3

The 1207 EKTN9/C3 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 4275 lbf and spins smoothly at speeds up to 13000 RPM.

Its double-row design and open construction allow for easy alignment adjustments, while the nylon cage reduces friction for quieter operation. The bearing comes pre-lubricated and works in temperatures from -30°C to 110°C.

With a C3 radial clearance, it accommodates slight misalignments, making it ideal for applications like conveyor systems or agricultural machinery. Weighing 0.32kg, it’s a robust yet manageable choice for various industrial uses.

Compliant with RoHS and REACH standards, it’s a reliable and safe option for replacements, especially where interchangeability with SKF bearings is needed.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 1207 EKTN9/C3
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 47 mm
  • Internal Diameter On Outer Ring 60.9 mm
  • Chamfer Dimension 1.1 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Taper 1:12
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 4275 lbf
  • Static Radial Load 1350 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance C3
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.32 kg
  • Price（$） 25.48
Self Aligning Ball Bearings 1207 EKTN9/C3 dimension drawing
Download DWG Download PDF

Features

Why Choose 1207 EKTN9/C3 Bearing for Precision Tasks?

1207 EKTN9/C3 Bearing features a double-row design with chrome steel rings and balls, ensuring high radial load capacity.
Its dynamic radial load rating of 4275 lbf makes it suitable for demanding applications.
The nylon cage helps reduce friction and noise, enhancing smooth operation.
With a maximum speed of 13,000 rpm, it offers both durability and efficiency.

Application

Industrial Uses of 1207 EKTN9/C3 Bearing
1207 EKTN9/C3 Bearing is commonly used in conveyor systems, where its self-aligning feature compensates for minor misalignments. The double-row design ensures stability even under heavy radial loads.

In automotive applications, 1207 EKTN9/C3 Bearing fits well in gearboxes and wheel hubs, providing smooth rotation. Its tapered bore allows for secure mounting, reducing slippage during operation.

For automation equipment, 1207 EKTN9/C3 Bearing supports robotic arms, ensuring precise movement. The nylon cage reduces friction, making it suitable for high-speed operations.

In household appliances like washing machines, 1207 EKTN9/C3 Bearing offers quiet and efficient performance. The chrome steel construction enhances durability in daily use.
