Self Aligning Ball Bearings 2307-2RS-TVH

Self Aligning Ball Bearings 2307-2RS-TVH

The 2307-2RS-TVH is a self-aligning ball bearing with a 35mm bore and 80mm outer diameter, designed for radial loads. Its compact 31mm width makes it suitable for tight spaces, while the double-row construction enhances stability.

Made from chrome steel with a nylon cage, it handles radial loads up to 5962 lbf and operates smoothly at speeds up to 5600 RPM. The sealed design keeps lubrication in and contaminants out, reducing maintenance needs.

This bearing works well in temperatures from -30°C to 110°C, making it versatile for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Ideal for applications like conveyor systems or agricultural machinery where misalignment might occur. Weighing 0.7kg, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 2307-2RS-TVH
  • Brand TFL & OEM
  • Interchangeable SKF
  • Bore Dia 35 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 80 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 31 mm
  • Width Tolerance -0.12mm to 0
  • External Diameter On Inner Ring 43.7 mm
  • Internal Diameter On Outer Ring 69.2 mm
  • Chamfer Dimension 1.5 mm
  • System of Measurement Metric
  • Bearing Type Ball
  • Bore Type Cylindrical
  • For Load Direction Radial
  • Construction Double Row
  • Seal Type Sealed
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 5962 lbf
  • Static Radial Load 1912 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Radial Clearance CN
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 5600 rpm
  • Weight 0.7 kg
  • Price（$） 80.85
Self Aligning Ball Bearings 2307-2RS-TVH dimension drawing
Download DWG Download PDF

Features

Why Choose 2307-2RS-TVH Bearing for Precision Tasks?

2307-2RS-TVH Bearing features a double-row design with chrome steel rings and balls, ensuring strong radial load capacity.
Its dynamic radial load reaches 5962 lbf, making it suitable for demanding applications.
The sealed construction and nylon cage help maintain smooth operation while reducing wear.
With a maximum speed of 5,600 rpm, it balances performance and durability in various conditions.

Application

Industrial Uses of 2307-2RS-TVH Bearing
2307-2RS-TVH Bearing is commonly used in industrial machinery like conveyor systems and mixers, where its self-aligning feature helps compensate for minor misalignments. The sealed design keeps contaminants out, ensuring longer service life in dusty environments.

In automotive applications, 2307-2RS-TVH Bearing is found in wheel hubs and transmissions, providing reliable radial load support. Its nylon cage reduces friction, making it suitable for high-speed rotations.

For automation equipment, 2307-2RS-TVH Bearing ensures smooth operation in robotic arms and assembly lines. The chrome steel construction offers durability, while the lubricated design minimizes maintenance needs.

In household appliances like washing machines, 2307-2RS-TVH Bearing handles radial loads effectively. The sealed design prevents grease leakage, keeping the appliance running quietly and efficiently.
