Self Aligning Ball Bearings 11207 TN9

Brand: TFL Bearing Interchangeable: SKF 11207 TN9 35 mm × 72 mm × 52 mm Metric Open
Part number: 11207 TN9
Self Aligning Ball Bearings 11207 TN9
In Stock
US$34.86 / piece
Reference price · volume pricing on request
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia35 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia72 mm
Outer Dia Tolerance-0.013mm to 0
Width52 mm
Width Tolerance-0.12mm to 0
External Diameter On Inner Ring47 mm
Internal Diameter On Outer Ring60.9 mm
Chamfer Dimension1.1 mm
Performance
Dynamic Radial Load4,275 lbf
Static Radial Load1,350 lbf
Temperature Range-30° to 110 °C
Max Speed5,600 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionRadial
ConstructionDouble Row
Seal TypeOpen
LubricationLubricated
Weight0.54 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialNylon
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 11207 TN9 is a self-aligning ball bearing with a 35mm bore and 72mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 4275 lbf and operates smoothly at speeds up to 5600 RPM.

Its double-row design and nylon cage provide flexibility and durability, making it suitable for misaligned shafts. The open seal allows for easy lubrication, enhancing its performance in various conditions.

This bearing works well in temperatures ranging from -30°C to 110°C, ideal for industrial machinery or automotive applications. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 0.54kg, it balances strength and practicality. Compliant with RoHS and REACH standards, it ensures safe and eco-friendly use.

Features

Why Choose 11207 TN9 Bearing for Precision Tasks?

11207 TN9 Bearing features a double-row design with chrome steel rings and balls, ensuring precise radial load handling.
Its dynamic radial load capacity of 4275 lbf makes it suitable for demanding applications.

The nylon cage maintains ball alignment, reducing friction and noise during operation.
With a maximum speed of 5,600 rpm, it offers a balance of performance and durability.

11207 TN9 Bearing operates smoothly in temperatures from -30° to 110°C, adapting to various environments.
Its open design allows for easy lubrication, enhancing long-term reliability.

The metric dimensions (35 mm×72 mm×52 mm) ensure compatibility with standard systems.
This bearing is interchangeable with SKF models, providing flexibility in replacements.

Application

Industrial Uses of 11207 TN9 Bearing
The 11207 TN9 Bearing is commonly used in industrial settings, especially in conveyor systems and heavy machinery where misalignment can occur. Its double-row design helps accommodate slight shaft deflections, ensuring smooth operation.

Where Is 11207 TN9 Bearing Used?
You’ll often find the 11207 TN9 Bearing in automotive applications like gearboxes and wheel hubs, where radial load support is essential. Its chrome steel construction provides durability under constant stress.

Built for Heavy-Duty Use: 11207 TN9 Bearing
The 11207 TN9 Bearing works well in agricultural equipment, handling rough conditions like dust and vibrations. The nylon cage reduces friction, making it a reliable choice for long-term use.

Automotive vs Aerospace: Applications of 11207 TN9 Bearing
In automotive systems, the 11207 TN9 Bearing supports radial loads in transmissions, while in aerospace, its precision suits auxiliary equipment. The metric sizing ensures compatibility across industries.

Perfect Fit for Automation: 11207 TN9 Bearing
The 11207 TN9 Bearing is ideal for robotic arms and automated assembly lines, where smooth rotation is key. Its open design allows for easy lubrication, reducing downtime.
