Needle Roller And Cage Assemblies K19x23x13

Needle Roller And Cage Assemblies K19x23x13

The K19x23x13 is a compact needle roller and cage assembly, measuring 19mm in bore diameter and 23mm in outer diameter. Its slim 13mm width makes it ideal for tight spaces.
Made from durable steel, it handles radial loads up to 2138 lbf and spins smoothly at speeds up to 21800 RPM. The single-row design ensures reliable performance under stress.
This assembly is interchangeable with INA bearings, offering a practical replacement option. It works well in temperatures from -30°C to 110°C, suitable for various industrial conditions.
Weighing just 8 grams, it’s lightweight yet robust. Perfect for applications like gearboxes, pumps, or small machinery where space is limited. Compliant with RoHS standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K19x23x13
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 19 mm
  • Outer Dia 23 mm
  • Width 13 mm
  • System of Measurement Metric
  • Roller Bearing Type Needle
  • Construction Single Row
  • Series K Series
  • Cage Material Steel
  • Needle Material Steel
  • Dynamic Radial Load 2138 lbf
  • Static Radial Load 3038 lbf
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • Max Speed 21800 rpm
  • Weight 8 g
Needle Roller And Cage Assemblies K19x23x13 dimension drawing
Download DWG Download PDF

Features

How Does K19x23x13 Bearing Achieve High-Speed Performance?
K19x23x13 Bearing features a steel cage and needles, providing robust support for dynamic radial loads up to 2138 lbf.
Its compact design with a 19 mm bore and 23 mm outer diameter ensures efficient space utilisation.
The steel construction allows K19x23x13 Bearing to operate smoothly at speeds up to 21,800 rpm.
With a temperature range of -30° to 110°C, it performs reliably in various environments.
K19x23x13 Bearing’s single-row design simplifies installation while maintaining high load capacity.
Its lightweight construction at just 8 grams reduces overall system weight without compromising strength.

Application

Key Fields for K19x23x13 Bearing
K19x23x13 Bearing is widely used in industrial gearboxes, where its compact design and high load capacity make it ideal for tight spaces. The steel construction ensures durability even in demanding environments.
In automotive applications, K19x23x13 Bearing fits well in transmission systems, providing smooth operation under high radial loads. Its metric sizing makes it a versatile choice for various vehicle models.
For automation equipment, K19x23x13 Bearing supports precise movements in robotic arms and conveyor systems. The high-speed capability allows it to handle rapid cycles without compromising performance.
In medical devices, K19x23x13 Bearing offers reliable performance in imaging equipment and lab instruments. Its lightweight design and compliance with RoHS standards make it suitable for sensitive environments.
