Metric Single Direction Thrust Ball Bearing 1013

Brand: TFL Bearing Interchangeable: SKF 1013 65 mm × 90 mm × 20 mm Metric Open
Part number: 1013
Metric Single Direction Thrust Ball Bearing 1013
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.015mm to 0
Outer Dia90 mm
Outer Dia Tolerance-0.02mm to 0
Width20 mm
Width Tolerance+0.02mm to -0.3mm
Inner Dia Housing Washer65.2 mm
Chamfer Dimension0.5 mm
Performance
Dynamic Thrust Load2,365 lbf
Static Thrust Load19,300 lbf
Temperature Range-30° to 110 °C
Max Speed3,740 rpm
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionThrust
Seal TypeOpen
LubricationRequired
Weight0.41 kg
Material
Ring Material52100 Chrome Steel
Ball Material52100 Chrome Steel
Cage MaterialChrome Steel
Compliance
RoHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 1013 is a single-direction thrust ball bearing with a 65mm bore and 90mm outer diameter, crafted from sturdy 52100 chrome steel. It manages thrust loads up to 2365 lbf and operates smoothly at speeds up to 3740 RPM.

Its open design simplifies lubrication, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for applications like pumps or machinery where single-direction thrust loads are present.

Weighing 0.41kg, it balances strength and portability. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Why Choose 1013 Bearing for Precision Tasks?

1013 Bearing is crafted from 52100 chrome steel, offering a strong and durable solution for thrust applications.
Its dynamic thrust load capacity of 2365 lbf ensures reliable performance under pressure.

The chrome steel cage maintains ball alignment, reducing friction and wear over time.
With a maximum speed of 3,740 rpm, it balances precision and efficiency.

1013 Bearing operates smoothly within a temperature range of -30° to 110°C.
Its open design simplifies lubrication, ensuring consistent performance in various conditions.

Application

Industrial Uses of 1013 Bearing
1013 Bearing is commonly used in heavy machinery like hydraulic presses and industrial pumps, where its single-direction thrust design handles axial loads effectively. The open seal type simplifies lubrication, making it suitable for environments requiring frequent maintenance.

In automotive applications, 1013 Bearing fits well in gearbox assemblies, providing reliable performance under high thrust loads. Its chrome steel construction ensures durability, even in demanding driving conditions.

For automation systems, 1013 Bearing supports robotic arms and conveyor belts, where precise movement is essential. The metric sizing allows easy integration with standard European and Asian equipment.

Medical devices like MRI machines benefit from 1013 Bearing’s consistent performance and low maintenance needs. The chrome steel cage adds extra resistance to wear in high-use medical environments.

Around the home, 1013 Bearing can be found in appliances like washing machines, where its robust design handles repetitive motion smoothly. The temperature range makes it adaptable to various household conditions.
