Inner Rings LR50X55X20.5

Brand: TFL Bearing Interchangeable: INA LR50X55X20.5 50 mm × 55 mm × 20.5 mm Metric
Part number: LR50X55X20.5
Inner Rings LR50X55X20.5
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia50 mm
Bore Dia Tolerance-0.013mm to 0.003mm
Outer Dia55 mm
Outer Dia Tolerance-0.019mm to 0
Width20.5 mm
Width Tolerance0 to 0.21mm
Characteristics
System of MeasurementMetric
Roller Bearing TypeNeedle
SeriesLR
LubricationLubricated
Weight64.1 g
Rmin0.6 mm
Material
MaterialChrome Steel
Compliance
RoHSCompliant
Dimension drawing · click to enlarge

Description

The LR50X55X20.5 is a needle roller bearing inner ring with a 50mm bore and 55mm outer diameter, crafted from sturdy chrome steel. Its 20.5mm width and precise tolerances ensure a snug fit in demanding applications.
Pre-lubricated for smooth operation, this ring reduces friction and wear in high-load scenarios. The 30° chamfer angle makes installation easier, while the 0.6mm minimum corner radius enhances durability.
Compatible with INA bearings, it’s a practical choice for replacements or upgrades. Ideal for gearboxes, transmissions, or industrial machinery where space is limited but performance is key.
Weighing just 64.1g, it’s lightweight yet robust. RoHS compliant for safe use in various environments.

Features

How Is LR50X55X20.5 Bearing Engineered for Reliability?
LR50X55X20.5 Bearing is crafted from high-quality chrome steel, ensuring durability and resistance to wear.
Its precise bore diameter tolerance of -0.013mm to 0.003mm guarantees a perfect fit for various applications.
The needle roller design reduces friction, making it ideal for high-speed operations.
With a chamfer angle of 30°, it allows for easier installation and alignment.

Application

Industrial Uses of LR50X55X20.5 Bearing
LR50X55X20.5 Bearing is commonly used in industrial gearboxes, where its needle roller design handles high radial loads efficiently. The chrome steel construction ensures durability in demanding environments.
In automotive applications, LR50X55X20.5 Bearing fits well in transmission systems, providing smooth operation under heavy stress. Its metric dimensions make it a versatile choice for various vehicle models.
For automation equipment, LR50X55X20.5 Bearing’s compact design is ideal for robotic arms and precision machinery. The lubricated feature reduces friction, enhancing performance in continuous operations.
Where Is LR50X55X20.5 Bearing Used?
You’ll often find LR50X55X20.5 Bearing in conveyor systems, where its needle rollers manage heavy loads with ease. The precise tolerances ensure reliable performance over time.
In household appliances like washing machines, LR50X55X20.5 Bearing supports rotating parts quietly and efficiently. Its chrome steel material resists wear, extending the appliance’s lifespan.
Built for Heavy-Duty Use: LR50X55X20.5 Bearing
LR50X55X20.5 Bearing excels in construction equipment, handling rugged conditions without faltering. The lubricated design keeps it running smoothly even under constant stress.
In agricultural machinery, LR50X55X20.5 Bearing’s robust build withstands dirt and debris. Its needle rollers provide the strength needed for heavy loads in tractors and harvesters.
Automotive vs Aerospace: Applications of LR50X55X20.5 Bearing
In cars, LR50X55X20.5 Bearing is trusted for steering systems, offering precision and reliability. The metric sizing ensures compatibility with a wide range of models.
For aerospace components, LR50X55X20.5 Bearing’s lightweight design and durability make it suitable for auxiliary systems. Its chrome steel construction meets stringent industry standards.
