FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP210-E-XL-TVP2-F1-J20AA-C4

FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP210-E-XL-TVP2-F1-J20AA-C4

The FAG NUP210-E-XL-TVP2-F1-J20AA-C4 is a current-insulated cylindrical roller bearing with a 50mm bore and 90mm outer diameter, designed to handle electrical currents. Its outer ring features a ceramic coating for insulation, preventing electrical damage.

With a dynamic load rating of 75 kN and a static load rating of 69 kN, it handles heavy radial loads efficiently. The plastic cage ensures smooth operation at speeds up to 6600 rpm.

The C4 radial clearance allows for thermal expansion, making it suitable for high-speed applications. The insulation can withstand up to 1000V, ideal for electric motors or generators.

Weighing 0.515kg, it’s a robust yet lightweight solution for industrial machinery. Compliant with RoHS and REACH standards, it’s safe for various environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model NUP210-E-XL-TVP2-F1-J20AA-C4
  • Product Category Current-Insulated Cylindrical Roller Bearing Single Row
  • Insulating Coating Types Outer ring ceramic coated
  • Coating Suffix J20AA
  • Manufacturers FAG
  • Bore Diameter 50.0 mm
  • Outside Diameter 90.0 mm
  • Width 20.0 mm
  • Net Weight 0.515 kg
  • Basic Dynamic Load Rating 75 kN
  • Basic Static Load Rating 69 kN
  • Reference Speed 6600r/min
  • Breakdown Voltage (DC) ≤1000v
  • Layer Thic kNess 200 um
  • Electrical Resistance 50MΩ (Dry); 10MΩ (Damp)
  • Cage Material P - Plastic Molded Cage
  • Radial Internal Clearance C4
  • ROHS Compliant
  • REACH Compliant
FAG Current-Insulated Single Row Cylindrical Roller Bearing NUP210-E-XL-TVP2-F1-J20AA-C4 dimension drawing
Download DWG Download PDF

Features

How Is NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing Engineered for Reliability?

NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing features an outer ring ceramic coating, providing excellent current insulation.
This design prevents electrical damage, ensuring reliable operation in electrically active environments.

The plastic molded cage maintains smooth rotation, reducing friction and wear.
With a basic dynamic load rating of 75 kN, it handles heavy loads efficiently.

NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing’s C4 radial internal clearance allows for thermal expansion.
This makes it suitable for high-speed applications up to 6,600 rpm.

The coating offers high electrical resistance, even in damp conditions.
This ensures consistent performance and longevity in varied environments.

Application

Industrial Uses of NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing
NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing is commonly used in electric motors and generators, where its current-insulating coating prevents electrical arcing. The ceramic outer ring coating ensures reliable performance in environments with stray currents.

In wind turbines, NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing handles high radial loads while maintaining electrical insulation. Its plastic cage reduces friction, making it suitable for high-speed applications.

For industrial pumps, NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing’s C4 clearance accommodates thermal expansion, ensuring smooth operation. The robust design also makes it a dependable choice for heavy machinery.

In railway applications, NUP210-E-XL-TVP2-F1-J20AA-C4 Bearing’s insulation properties protect against electrical damage. Its high dynamic load rating ensures longevity in demanding conditions.
