SKF INSOCOAT Bearings 6224M/C4VL0241

SKF INSOCOAT Bearings 6224M/C4VL0241

The SKF INSOCOAT 6224M/C4VL0241 is a robust bearing with a 120mm bore and 215mm outer diameter, designed for heavy-duty applications. Its outer ring features a 500µm insulating coating to prevent electrical damage, making it ideal for environments with stray currents.

With a dynamic load rating of 146kN and a static load rating of 118kN, it handles high loads effortlessly. The brass cage ensures smooth operation at speeds up to 6300 RPM, while the C4 radial clearance accommodates thermal expansion.

The insulation coating provides a breakdown voltage of up to 3000V and an electrical resistance of 200MΩ, protecting against electrical arcing. This makes it suitable for use in electric motors or generators where electrical insulation is crucial.

Weighing 6.4kg, it’s a durable choice for industrial machinery. Compliant with ROHS standards, it’s both reliable and environmentally friendly. Perfect for applications requiring both mechanical strength and electrical insulation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6224M/C4VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 120.0 mm
  • Outside Diameter 215.0 mm
  • Width 40.0 mm
  • Net Weight 6.4kg
  • Basic Dynamic Load Rating 146.0 kN
  • Basic Static Load Rating 118.0 kN
  • Reference Speed 6300.0 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C4
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6224M/C4VL0241 dimension drawing
Download DWG Download PDF

Features

How Is 6224M/C4VL0241 Bearing Engineered for Reliability?

6224M/C4VL0241 Bearing features an insulation coating on the outer ring, preventing electrical damage in high-voltage environments.
Its brass cage ensures smooth operation and reduces friction, even at high speeds up to 6,300 r/min.

The bearing’s C4 radial internal clearance allows for thermal expansion, maintaining performance under varying temperatures.
With a basic dynamic load rating of 146 kN, it handles heavy loads reliably.

The 500 µm coating thickness provides consistent insulation, with a breakdown voltage of up to 3,000 V.
This makes 6224M/C4VL0241 Bearing suitable for applications where electrical resistance is crucial.

Application

Industrial Uses of 6224M/C4VL0241 Bearing
The 6224M/C4VL0241 Bearing is commonly used in electric motors, where its insulating coating prevents electrical currents from damaging the bearing.
This makes it ideal for industries relying on high-voltage equipment, such as power generation and industrial automation.

Why Is 6224M/C4VL0241 Bearing Essential in Machinery?
In conveyor systems, the 6224M/C4VL0241 Bearing handles heavy loads while maintaining smooth operation.
Its brass cage and C4 clearance ensure durability even in demanding environments.

Perfect Fit for Automation: 6224M/C4VL0241 Bearing
Robotic arms benefit from the 6224M/C4VL0241 Bearing’s high-speed capabilities and insulation properties.
The bearing’s design reduces downtime, making it a reliable choice for automated production lines.

Medical vs Industrial: Where 6224M/C4VL0241 Bearing Excels
While not typically used in medical devices, the 6224M/C4VL0241 Bearing shines in industrial settings like pumps and compressors.
Its resistance to electrical currents and high load capacity make it versatile for various applications.
