SKF INSOCOAT Bearings 6344M/C3VL0241

SKF INSOCOAT Bearings 6344M/C3VL0241

The SKF INSOCOAT bearing 6344M/C3VL0241 is a robust unit with a 220mm bore and 460mm outer diameter, designed for heavy-duty applications. Its outer ring features a 500µm insulating coating, providing protection against electrical currents.

With a dynamic load rating of 440kN and static load rating of 560kN, it handles substantial loads while maintaining smooth operation. The brass cage ensures durability, and the C3 radial clearance allows for thermal expansion.

The insulation coating offers a breakdown voltage of up to 3000V, making it ideal for electric motors or generators where electrical resistance is crucial. It’s also RoHS compliant for safe use in various industries.

Weighing 72.8kg, this bearing is suited for large machinery requiring reliable performance under high electrical and mechanical stress. Its reference speed of 2460 r/min ensures efficient operation in demanding conditions.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Model 6344M/C3VL0241
  • Product Category INSOCOAT Bearings
  • Insulating Coating Types Insulation coating on outer ring
  • Coating Suffix VL0241
  • Manufacturers SKF
  • Bore Diameter 220.0 mm
  • Outside Diameter 460.0 mm
  • Width 88.0 mm
  • Net Weight 72.8 kg
  • Basic Dynamic Load Rating 440.0 kN
  • Basic Static Load Rating 560.0 kN
  • Reference Speed 2460 r/min
  • Breakdown Voltage (DC) ≤3000 V
  • Layer Thickness 500 µm
  • Electrical Resistance 200 MΩ
  • Cage Material Brass cage
  • Radial Internal Clearance C3
  • ROHS Compliant
  • REACH Compliant
SKF INSOCOAT Bearings 6344M/C3VL0241 dimension drawing
Download DWG Download PDF

Features

Performance Features of 6344M/C3VL0241 Bearing

6344M/C3VL0241 Bearing features an insulation coating on the outer ring, providing protection against electrical currents.
The coating has a breakdown voltage of up to 3000 V, making it suitable for electric motor applications.

With a basic dynamic load rating of 440 kN, 6344M/C3VL0241 Bearing handles heavy loads efficiently.
Its brass cage ensures smooth operation and reduces friction during high-speed rotation.

The C3 radial internal clearance allows for thermal expansion, enhancing performance in varying temperatures.
This design ensures reliable operation even in demanding industrial environments.

6344M/C3VL0241 Bearing’s insulation coating has an electrical resistance of 200 MΩ, preventing current passage.
This feature extends the bearing’s lifespan in electrically charged applications.

Application

Industrial Uses of 6344M/C3VL0241 Bearing
The 6344M/C3VL0241 Bearing is commonly used in heavy industrial machinery, such as large electric motors and generators, where its insulation coating prevents electrical damage.
Its brass cage and C3 clearance make it suitable for high-load applications, ensuring smooth operation even under demanding conditions.

Where Is 6344M/C3VL0241 Bearing Used?
You’ll often find the 6344M/C3VL0241 Bearing in wind turbines, where its high dynamic load rating and insulation properties are essential for reliable performance.
The bearing’s robust design also makes it a good fit for mining equipment, handling heavy loads with ease.

Built for Heavy-Duty Use: 6344M/C3VL0241 Bearing
The 6344M/C3VL0241 Bearing excels in steel mills, where its insulation coating protects against stray currents that can cause premature failure.
Its high reference speed and static load rating ensure it can handle the intense demands of continuous operation.

Automotive vs Aerospace: Applications of 6344M/C3VL0241 Bearing
In automotive testing equipment, the 6344M/C3VL0241 Bearing provides reliable performance due to its insulation and high load capacity.
While not typically used in aerospace, its durability makes it a solid choice for ground-based support machinery in the industry.

Perfect Fit for Automation: 6344M/C3VL0241 Bearing
The 6344M/C3VL0241 Bearing is ideal for automated production lines, where its insulation coating prevents electrical interference.
Its brass cage and C3 clearance ensure smooth operation, reducing downtime in high-speed manufacturing environments.
