Drawn Cup Needle Roller Bearings BCH1016

Drawn Cup Needle Roller Bearings BCH1016

The BCH1016 is a drawn cup needle roller bearing with a 0.625″ bore and 0.875″ outer diameter, crafted from sturdy steel for reliable performance. It handles radial loads up to 4316 lbf and spins smoothly at speeds up to 15300 RPM.
Its open design and press-fit mounting make installation straightforward, while the steel cage ensures durability. The bearing operates well in temperatures ranging from -20°C to 110°C.
This model is interchangeable with INA bearings, offering a practical replacement option. Ideal for applications like automotive components or small machinery where space is limited.
Regular lubrication is recommended to maintain its performance. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCH1016
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 0.625"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 0.875"
  • Outer Dia Tolerance Not Rated
  • Width 1"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 4316 lbf
  • Static Radial Load 6295 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 15300 rpm
  • Weight 25 g
Drawn Cup Needle Roller Bearings BCH1016 dimension drawing
Download DWG Download PDF

Features

How Does BCH1016 Bearing Handle High-Speed Applications?
BCH1016 Bearing is built with a steel construction, offering robust performance under radial loads.
Its dynamic radial load capacity of 4316 lbf ensures reliability in demanding conditions.
The press-fit shaft mount design simplifies installation, saving time and effort.
With a maximum speed of 15,300 rpm, it excels in high-speed applications while maintaining durability.

Application

Industrial Uses of BCH1016 Bearing
BCH1016 Bearing works well in compact spaces, like conveyor systems, where its needle roller design handles radial loads efficiently. The steel construction ensures durability even in demanding industrial settings.
Where Is BCH1016 Bearing Used?
You’ll often spot BCH1016 Bearing in automotive gearboxes, where its press-fit design simplifies installation. Its high-speed capability makes it a reliable choice for smooth power transmission.
Built for Heavy-Duty Use: BCH1016 Bearing
In robotics, BCH1016 Bearing supports joint movements, thanks to its precise radial load capacity. The open seal allows for easy lubrication, extending its service life.
Automotive vs Industrial: Applications of BCH1016 Bearing
BCH1016 Bearing fits seamlessly into both car transmissions and factory machinery. Its inch sizing makes it versatile for various equipment designs.
Perfect Fit for Automation: BCH1016 Bearing
BCH1016 Bearing is a go-to for automated assembly lines, where consistent performance matters. The steel cage keeps everything running smoothly under high loads.
