Drawn Cup Needle Roller Bearings BCE2812

Drawn Cup Needle Roller Bearings BCE2812

The BCE2812 is a drawn cup needle roller bearing with a 1.75″ bore and 2.125″ outer diameter, made from sturdy steel. It handles radial loads up to 7081 lbf and can spin at speeds up to 6300 RPM.
Its open, single-row design with a press-fit mount ensures easy installation and reliable performance. The steel construction offers durability in temperatures ranging from -20°C to 110°C.
This model is interchangeable with INA bearings, making it a practical choice for replacements. Ideal for applications like automotive components or industrial machinery where radial loads are common.
Regular lubrication is needed to maintain smooth operation. Compliant with RoHS standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number BCE2812
  • Brand TFL
  • Interchangeable INA
  • Bore Dia 1.75"
  • Bore Dia Tolerance Refer to note on the right drawing
  • Outer Dia 2.125"
  • Outer Dia Tolerance Not Rated
  • Width 0.75"
  • Width Tolerance -0.01" to 0"
  • System of Measurement Inch
  • Bearing Type Roller
  • Roller Bearing Type Needle
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Series Closed End
  • Ring Material Steel
  • Ball Material Steel
  • Cage Material Steel
  • Dynamic Radial Load 7081 lbf
  • Static Radial Load 12364 lbf
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range -20 to 110 °C
  • RoHS Compliant
  • Max Speed 6300 rpm
  • Weight 82 g
Drawn Cup Needle Roller Bearings BCE2812 dimension drawing
Download DWG Download PDF

Features

How Does BCE2812 Bearing Handle Heavy Loads?
BCE2812 Bearing is built with steel rings and needles, offering strong resistance to heavy radial loads.
Its dynamic radial load capacity reaches 7081 lbf, ensuring reliable performance in demanding applications.
The steel cage maintains needle alignment, reducing wear and extending service life.
With a maximum speed of 6300 rpm, it combines durability and efficiency for various industrial uses.

Application

Industrial Uses of BCE2812 Bearing
BCE2812 Bearing is commonly used in industrial gearboxes, where its needle roller design efficiently handles high radial loads. The press-fit mounting ensures a secure installation, reducing maintenance needs in demanding environments.
Where Is BCE2812 Bearing Used?
You’ll often find BCE2812 Bearing in automotive transmissions, providing smooth operation under heavy loads. Its steel construction offers durability, making it a reliable choice for long-term use.
Built for Heavy-Duty Use: BCE2812 Bearing
BCE2812 Bearing excels in construction equipment, such as compact hydraulic systems, thanks to its robust design. The open seal type allows for easy lubrication, extending its service life.
Automotive vs Industrial: Applications of BCE2812 Bearing
In automotive applications, BCE2812 Bearing supports components like steering columns, while in industrial settings, it’s ideal for conveyor systems. Its inch sizing makes it versatile for various machinery.
Perfect Fit for Automation: BCE2812 Bearing
BCE2812 Bearing works well in robotic arms, where precision and load capacity are key. The steel cage ensures stability, even during high-speed operations.
