Double Row Angular Contact Ball Bearings (General) 3308 A-2RS1

Brand: TFL Bearing Interchangeable: SKF 3308 A-2RS1 40 mm × 90 mm × 36.5 mm Metric Sealed
Part number: 3308 A-2RS1
Double Row Angular Contact Ball Bearings (General) 3308 A-2RS1
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia40 mm
Bore Dia Tolerance-0.01mm to 0
Outer Dia90 mm
Outer Dia Tolerance-0.013mm to 0
Width36.5 mm
Width Tolerance-0.05mm to 0
Chamfer Dimension1.5 mm
Performance
Dynamic Radial Load14,738 lbf
Static Radial Load10,800 lbf
Max Speed5,000 rpm
Temperature Range-30° to 110 °C
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionAngular Contact
ConstructionDouble Row
Seal TypeSealed
Distance Pressure Point (a)53 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight0.93 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialStainless Steel
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 3308 A-2RS1 is a double-row angular contact ball bearing with a 40mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 14738 lbf and operates smoothly at speeds up to 5000 RPM.

Its sealed design keeps lubrication in and contaminants out, while the stainless steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like pumps or gearboxes where angular contact and radial loads are present.

Weighing 0.93kg, it offers a robust build for its size. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Features

Performance Features of 3308 A-2RS1 Bearing

3308 A-2RS1 Bearing is built with chrome steel rings and balls, offering high resistance to radial loads.
Its dynamic radial load capacity reaches 14,738 lbf, making it suitable for heavy-duty applications.

The double-row design enhances stability and load distribution, ensuring smooth operation.
With a maximum speed of 5,000 rpm, it balances performance and durability.

Sealed construction protects 3308 A-2RS1 Bearing from dust and moisture, extending its service life.
The stainless steel cage maintains ball alignment, reducing friction and wear.

3308 A-2RS1 Bearing operates efficiently in temperatures from -30° to 110°C.
Its precision P6 tolerance class ensures reliable performance in demanding conditions.

Application

Industrial Uses of 3308 A-2RS1 Bearing
The 3308 A-2RS1 Bearing is commonly used in machine tools, where its double-row design handles combined radial and axial loads efficiently. The sealed construction keeps contaminants out, extending service life in dusty workshops.

Where Is 3308 A-2RS1 Bearing Used?
You’ll often find 3308 A-2RS1 Bearing in conveyor systems, supporting heavy loads with smooth rotation. Its chrome steel rings and stainless steel cage ensure durability in continuous operation.

Built for Heavy-Duty Use: 3308 A-2RS1 Bearing
In automotive applications like wheel hubs, 3308 A-2RS1 Bearing provides reliable performance under varying loads. The P6 tolerance class ensures precision fit for smoother rides.

Medical vs Industrial: Where 3308 A-2RS1 Bearing Excels
While 3308 A-2RS1 Bearing suits industrial gearboxes, its sealed design also works well in medical devices like centrifuges. The lubricated setup reduces maintenance needs in critical environments.

Perfect Fit for Automation: 3308 A-2RS1 Bearing
Robotic arms benefit from 3308 A-2RS1 Bearing’s angular contact design, which handles multidirectional forces. The metric sizing makes it easy to integrate into European automation systems.
