23226 CC/W64H Double Row Spherical Roller Bearing

23226 CC/W64H Double Row Spherical Roller Bearing

The 23226 CC/W64H is a double-row spherical roller bearing with a 130mm bore and 230mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 185692 lbf and operates smoothly at speeds up to 2600 RPM.

Its open design allows for easy lubrication, while the steel cage ensures durability under heavy loads. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery, gearboxes, or heavy equipment where combined loads are common.

Weighing 14kg, it’s built to handle demanding conditions while complying with RoHS and REACH standards. The lubrication groove and hole simplify maintenance, extending its service life.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23226 CC/W64H
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 230 x 80 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 230 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 80 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 151 mm
  • Shoulder/Recess Dia Of Outer Ring 196 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 185692 lbf
  • Static Radial Load 238297 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 14 kg

Features

Performance Features of 23226 CC/W64H Bearing

23226 CC/W64H Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 185692 lbf, making it suitable for heavy-duty applications.
The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2600 rpm, it delivers reliable performance in various industrial settings.

How Is 23226 CC/W64H Bearing Engineered for Reliability?

23226 CC/W64H Bearing features a steel cage that maintains roller alignment, reducing wear and extending lifespan.
The lubrication groove and holes ensure consistent oil flow, enhancing operational efficiency.
Its temperature range of -30° to 200°C allows it to perform in both cold and high-heat environments.
The spherical roller design compensates for shaft misalignment, improving overall reliability.

Built for Durability: 23226 CC/W64H Bearing

23226 CC/W64H Bearing’s chrome steel construction provides high resistance to wear and fatigue.
The double-row design distributes loads evenly, increasing bearing longevity.
With a static radial load capacity of 238297 lbf, it handles extreme conditions effortlessly.
Its robust design ensures minimal maintenance, reducing downtime and operational costs.

Application

Industrial Uses of 23226 CC/W64H Bearing
23226 CC/W64H Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads. The chrome steel construction ensures durability in harsh industrial environments.

Where Is 23226 CC/W64H Bearing Used?
In mining equipment, 23226 CC/W64H Bearing supports large rotating shafts, providing reliable performance under extreme conditions. Its high dynamic radial load capacity makes it suitable for continuous operation.

Built for Heavy-Duty Use: 23226 CC/W64H Bearing
23226 CC/W64H Bearing excels in paper mill machinery, where its spherical rollers accommodate shaft deflections. The steel cage enhances stability, even at high speeds.

Automotive vs Aerospace: Applications of 23226 CC/W64H Bearing
In automotive applications, 23226 CC/W64H Bearing is found in large trucks and buses, handling combined loads. For aerospace, it’s used in ground support equipment due to its robust design.

Practical Applications of 23226 CC/W64H Bearing
23226 CC/W64H Bearing is ideal for wind turbines, where its ability to handle misalignment and heavy loads ensures long service life. The lubrication groove design simplifies maintenance.
