Double Row Cylindrical Roller Thrust Bearings 89426 M

Double Row Cylindrical Roller Thrust Bearings 89426 M

The 89426 M is a double-row cylindrical roller thrust bearing, measuring 130mm by 270mm by 85mm, crafted from sturdy chrome steel for long-lasting use. It handles heavy thrust loads up to 238500 lbf and operates smoothly at speeds up to 1100 RPM.

Its machined brass cage enhances durability, while the two-row roller design distributes loads evenly. The bearing performs reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. Suitable for heavy-duty applications like industrial presses or large gearboxes where high thrust loads are expected.

Weighing 27kg, it’s built for robust performance. Compliant with RoHS and REACH standards, ensuring safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89426 M
  • Size 130 mm x 270 mm x 85 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 270 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 85 mm
  • Height Tolerance -0.40mm to +0.025mm
  • Outside Diameter Shaft Washer 270 mm
  • Bore Diameter Housing Washer 134 mm
  • Height Shaft Washer 28.5 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 4 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 238500 lbf
  • Static Radial Load 1012500 lbf
  • Max Speed 1100 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 27 kg
  • Roller And Cage Thrust Assembly K 89426 M
  • Shaft Washer WS 89426
  • Housing Washer GS 89426
Double Row Cylindrical Roller Thrust Bearings 89426 M dimension drawing
Download DWG Download PDF

Features

Performance Features of 89426 M Bearing

89426 M Bearing is built with chrome steel washers and rollers, offering robust resistance to heavy thrust loads.
Its dynamic radial load capacity reaches 238,500 lbf, making it suitable for demanding industrial applications.

The machined brass cage ensures precise roller alignment, reducing friction and enhancing durability.
With a maximum speed of 1,100 rpm, it delivers reliable performance under high-stress conditions.

89426 M Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its double-row cylindrical design provides stability and load distribution for long-term use.

Application

Industrial Uses of 89426 M Bearing
The 89426 M Bearing is commonly used in heavy machinery, such as hydraulic presses and large conveyor systems, where its double-row design handles significant thrust loads. Its chrome steel construction ensures durability in demanding environments.

What Makes 89426 M Bearing a Preferred Choice?
In wind turbines, 89426 M Bearing supports the rotor shaft, providing stability under high axial forces. The machined brass cage reduces friction, enhancing efficiency in long-term operations.

Built for Heavy-Duty Use: 89426 M Bearing
For steel rolling mills, 89426 M Bearing excels in handling extreme loads and high-speed rotations. Its precise tolerances and robust materials make it reliable for continuous industrial use.

Automotive vs Aerospace: Applications of 89426 M Bearing
In automotive applications, 89426 M Bearing is found in large gearboxes, while in aerospace, it supports landing gear mechanisms. Its versatility across industries highlights its adaptability.

Key Fields for 89426 M Bearing
The 89426 M Bearing is ideal for marine equipment, such as propeller shafts, where corrosion resistance and load capacity are critical. Its metric sizing ensures compatibility with international standards.
