22314 CC/C3 W33 Double Row Spherical Roller Bearing

22314 CC/C3 W33 Double Row Spherical Roller Bearing

The 22314 CC/C3 W33 is a double-row spherical roller bearing with a 70mm bore and 150mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 92846 lbf and operates smoothly at speeds up to 4500 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The open construction requires regular lubrication, with grooves and holes for easy maintenance.

This bearing suits high-load applications like industrial gearboxes or heavy machinery, where alignment flexibility is needed. It performs well in temperatures from -30°C to 200°C.

Weighing 4.3kg, it’s a robust choice for demanding environments. Compliant with RoHS and REACH standards, it’s interchangeable with SKF models for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22314 CC/C3 W33
  • Brand TFL
  • Interchangeable SKF
  • Size 70 x 150 x 51 mm
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Width 51 mm
  • Width Tolerance -0.06mm to 0
  • Shoulder Dia Of Inner Ring 90.3 mm
  • Shoulder/Recess Dia Of Outer Ring 128 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 92846 lbf
  • Static Radial Load 96668 lbf
  • Max Speed 4500 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 4.3 kg
  • Price （US$） 70.02

Features

Performance Features of 22314 CC/C3 W33 Bearing

22314 CC/C3 W33 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 92,846 lbf, ensuring reliable performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress and wear.
With a maximum speed of 4,500 rpm, it balances durability and efficiency in demanding conditions.

22314 CC/C3 W33 Bearing operates in temperatures from -30° to 200°C, making it suitable for varied environments.
The C3 radial clearance provides flexibility, accommodating thermal expansion during operation.

Steel cage construction ensures proper roller alignment, enhancing longevity and reducing maintenance needs.
Lubrication grooves and holes simplify maintenance, ensuring consistent performance over time.

Application

Industrial Uses of 22314 CC/C3 W33 Bearing
22314 CC/C3 W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction allows for slight misalignment, making it ideal for rugged environments.

What Makes 22314 CC/C3 W33 Bearing a Preferred Choice?
In mining equipment, 22314 CC/C3 W33 Bearing’s high dynamic load capacity ensures reliable performance under extreme conditions. The steel cage and chrome steel rollers provide durability, even in dusty or high-temperature settings.

Built for Heavy-Duty Use: 22314 CC/C3 W33 Bearing
For wind turbines, 22314 CC/C3 W33 Bearing supports the main shaft, offering stability and long service life. Its C3 radial clearance accommodates thermal expansion, which is crucial for consistent operation in varying climates.

Automotive vs Aerospace: Applications of 22314 CC/C3 W33 Bearing
In truck transmissions, 22314 CC/C3 W33 Bearing handles high loads and speeds with minimal maintenance. While not typically used in aerospace, its robust design suits other demanding transport applications.

Perfect Fit for Automation: 22314 CC/C3 W33 Bearing
22314 CC/C3 W33 Bearing works well in robotic arms, where precision and load capacity are key. The open design simplifies lubrication, ensuring smooth movement in automated systems.
