Home / Product / Ball Bearings / Deep Groove Ball Bearings / Single Row Deep Groove Ball Bearings With Filling Slots
Single Row Deep Groove Ball Bearings With Filling Slots
There is a ball loading gap on the inner and outer rings of the single-row deep groove ball bearing with a ball loading gap, which is used to load more steel balls, significantly improving the bearing’s radial load capacity. However, its axial load capacity is limited and it is not suitable for high axial load applications. To enhance axial load capacity, double-row deep groove ball bearings or angular contact ball bearings are often used instead. These bearings are designed to accommodate both radial and axial loads more effectively, ensuring smoother and more reliable operation under various conditions.
Loading...
Total 92 Results
Part Number
Brand
Bore Dia
Outer Dia
Width
System of Measurement
Bearing Type
For Load Direction
Dynamic Radial Load
Static Radial Load
Weight
Price($)
210-RS1
TFL
50 mm
90 mm
20 mm
Metric
Ball
Radial
8790 lbf
7756 lbf
0.5 kg
10.55
210-Z
TFL
50 mm
90 mm
20 mm
Metric
Ball
Radial
8790 lbf
7756 lbf
0.5 kg
14.68
210/C3
TFL
50 mm
90 mm
20 mm
Metric
Ball
Radial
8790 lbf
7756 lbf
0.5 kg
13.9
310
TFL
50 mm
110 mm
27 mm
Metric
Ball
Radial
14478 lbf
11690 lbf
1.15 kg
21
310 NA/C3L
TFL
50 mm
110 mm
27 mm
Metric
Ball
Radial
14478 lbf
11690 lbf
1.15 kg
13.66
310-2Z
TFL
50 mm
110 mm
27 mm
Metric
Ball
Radial
14478 lbf
11690 lbf
1.15 kg
25.44
310-Z
TFL
50 mm
110 mm
27 mm
Metric
Ball
Radial
14478 lbf
11690 lbf
1.15 kg
23.2
310/C3
TFL
50 mm
110 mm
27 mm
Metric
Ball
Radial
14478 lbf
11690 lbf
1.15 kg
22.96
211
TFL
55 mm
100 mm
21 mm
Metric
Ball
Radial
10881 lbf
9892 lbf
0.66 kg
16.42
211-2Z
TFL
55 mm
100 mm
21 mm
Metric
Ball
Radial
10881 lbf
9892 lbf
0.66 kg
19.38
211-Z
TFL
55 mm
100 mm
21 mm
Metric
Ball
Radial
10881 lbf
9892 lbf
0.66 kg
17.53
211-Z/C3
TFL
55 mm
100 mm
21 mm
Metric
Ball
Radial
10881 lbf
9892 lbf
0.66 kg
18.53
211/C3
TFL
55 mm
100 mm
21 mm
Metric
Ball
Radial
10881 lbf
9892 lbf
0.66 kg
17.9
311
TFL
55 mm
120 mm
29 mm
Metric
Ball
Radial
17805 lbf
15062 lbf
1.5 kg
25.8
Increase in Load Capacity with Filling Slots
Compared with ordinary deep groove ball bearings, single row deep groove ball bearings with filling slots have filling slots on both the inner and outer rings to accommodate more steel balls than ordinary deep groove ball bearings, thereby evenly distributing the weight and improving radial load capacity.
Key Application Scenarios
In demanding industrial environments, load capacity and durability are critical. For example, in applications such as heavy machinery, agricultural equipment, and motors.
TFL single row deep groove ball bearings with filling slots are designed for environments with frequent impact loads and continuous vibration, showing excellent durability and excellent stability.
Various Materials and Sealing Options
We offer a variety of bearing sizes and materials, including chrome steel that combines strength and economy, and corrosion-resistant stainless steel, to meet your needs in different environments.
Flexible sealing options, open or with dust covers on one or both sides, easy lubrication, help extend service life while minimizing maintenance.
FREQUENTLY ASKED QUESTIONS
What is the biggest difference from ordinary deep groove ball bearings?
Compared with ordinary single row deep groove ball bearings, the biggest difference is that it has filling slots on both the inner and outer rings, which can accommodate more balls and have higher radial load capacity, but cannot withstand large axial loads.
Will the filling slots make installation easier?
The filling slots are mainly used to fit more steel balls to increase the load capacity. For users, the installation method is similar to that of ordinary deep groove ball bearings. It does not significantly simplify installation, but provides better performance.
Does this bearing require frequent maintenance or lubrication?
Yes. Depending on the working conditions, it is recommended to check/relubricate every 1-3 months (regular lubrication). For dusty or high-load environments, more frequent maintenance may be required.
Do you offer samples? What is the Minimum Order Quantity (MOQ)?
Sample availability and Minimum Order Quantity (MOQ) can vary by product model. Please check the specific product page or contact our sales team for details on the bearing you need.
