Single Row Deep Groove Ball Bearings With Filling Slots 210-Z

Single Row Deep Groove Ball Bearings With Filling Slots 210-Z

The 210-Z is a single-row deep groove ball bearing with a 50mm bore and 90mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 8790 lbf and operates smoothly at speeds up to 8000 RPM.

Its shielded design keeps dirt out while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical replacement option. It’s well-suited for electric motors or conveyor systems where radial loads are typical.

Weighing 0.5kg, it balances durability with manageable size. Pre-greased and compliant with RoHS and REACH standards for safe, low-maintenance use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 210-Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 20 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Grade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 8790 lbf
  • Static Radial Load 7756 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8000 rpm
  • Weight 0.5 kg
  • Price（$） 14.68
Single Row Deep Groove Ball Bearings With Filling Slots 210-Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 210-Z Bearing

210-Z Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 8790 lbf, ensuring reliable performance in various applications.

The nylon cage in 210-Z Bearing keeps the balls aligned, reducing friction and wear.
With a maximum speed of 8,000 rpm, it balances durability and efficiency.

210-Z Bearing operates smoothly in temperatures ranging from -30° to 120°C.
Its shielded design helps keep contaminants out, extending its service life.

Application

Industrial Uses of 210-Z Bearing
210-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The nylon cage reduces friction, making it suitable for continuous operation.

In automotive applications, 210-Z Bearing fits well in wheel hubs and alternators, providing reliable radial load support. Its grease lubrication ensures smooth performance even under varying temperatures.

For home appliances, 210-Z Bearing works efficiently in washing machines and fans, thanks to its balanced design. The chrome steel construction offers durability for everyday use.

Automation systems benefit from 210-Z Bearing in robotic arms and conveyor belts, where precision and low maintenance are key. The metric sizing ensures compatibility with standard components.

Medical devices like centrifuges use 210-Z Bearing for its consistent performance and quiet operation. The P0 tolerance class guarantees reliable accuracy in sensitive equipment.
