Single Row Deep Groove Ball Bearings With Filling Slots 310-Z

Single Row Deep Groove Ball Bearings With Filling Slots 310-Z

The 310-Z is a single-row deep groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It supports radial loads up to 14478 lbf and operates smoothly at speeds up to 7000 RPM.

Its shielded design keeps dirt out while the nylon cage reduces friction for quieter performance. The bearing works reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a practical alternative for replacements. Suitable for applications like electric motors or pumps where radial loads are common.

Weighing 1.15kg, it balances durability with manageable size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 310-Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Grade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Nylon
  • Dynamic Radial Load 14478 lbf
  • Static Radial Load 11690 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 1.15 kg
  • Price（$） 23.2
Single Row Deep Groove Ball Bearings With Filling Slots 310-Z dimension drawing
Download DWG Download PDF

Features

Performance Features of 310-Z Bearing

310-Z Bearing is built with chrome steel rings and balls, offering strong radial load capacity up to 14478 lbf.
Its shielded design protects against contaminants while maintaining smooth operation.

The nylon cage in 310-Z Bearing ensures quiet performance and reduces friction.
With a maximum speed of 7,000 rpm, it balances durability and efficiency in various applications.

310-Z Bearing operates reliably in temperatures from -30° to 120°C.
Its grease lubrication reduces maintenance needs, making it a practical choice for long-term use.

Application

Industrial Uses of 310-Z Bearing
The 310-Z Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. Its high dynamic radial load capacity makes it suitable for continuous operation in demanding environments.

In automotive applications, 310-Z Bearing can be found in wheel hubs and transmission systems, providing reliable performance under radial loads. The nylon cage reduces friction, contributing to smoother operation and longer service life.

For automation equipment, 310-Z Bearing supports robotic arms and conveyor systems with its balanced load distribution. The grease lubrication ensures consistent performance even at higher speeds.

Around the home, 310-Z Bearing works well in appliances like washing machines, where durability and quiet operation are key. Its metric sizing makes it easy to replace in various European and Asian models.
