TS (Single Row Tapered Roller Bearings) (Imperial) 99603-99100

TS (Single Row Tapered Roller Bearings) (Imperial) 99603-99100

The 99603-99100 is a single-row tapered roller bearing with a 6″ bore and 10″ outer diameter, built from sturdy chrome steel. It handles combined loads up to 132,000 lbf radially and 23,800 lbf thrust, suitable for heavy-duty applications.

Its open design allows easy lubrication, while the steel cage ensures durability under high stress. The bearing operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for industrial machinery, gearboxes, or construction equipment where robust performance is needed.

Weighing 28.1 lb, it’s designed for stability and long service life. Compliant with RoHS and REACH standards, it’s a reliable option for various engineering needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 99603-99100
  • Brand TFL
  • Interchangeable Timken
  • Size 6" x 10" x 2.625"
  • Bore Dia 6"
  • Bore Dia Tolerance +0.001" to 0
  • Outer Dia 10"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 2.8125"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 1.875"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 2.625"
  • Width Tolerance +0.014" to -0.01"
  • Cone Backface ToClear Radius 0.06"
  • Cup Backface ToClear Radius 0.130"
  • Cone Frontface Backing Diameter 7.52"
  • Cone Backface Backing Diameter 6.69"
  • Cup Frontface Backing Diameter 9.38"
  • Cup Backface Backing Diameter 8.94"
  • Cage Cone Frontface Clearance 0.03"
  • Cage Cone Backface Clearance 0.34"
  • Effective Center Location -0.48"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 99603
  • Cup Part Number 99100
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 99000
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 132000 lbf
  • Static Radial Load 211000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 34100 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 23800 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 28.1 lb

Features

Performance Features of 99603-99100 Bearing

99603-99100 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 132,000 lbf, making it suitable for heavy-duty applications.

The steel cage maintains roller alignment, ensuring smooth operation and reduced wear.
With a temperature range of -30° to 110°C, it performs reliably in various conditions.

99603-99100 Bearing’s standard radial clearance allows for flexibility in different setups.
Its ABEC-1 rating ensures consistent performance for industrial needs.

Application

Industrial Uses of 99603-99100 Bearing
99603-99100 Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined radial and thrust loads effectively. The chrome steel construction ensures durability in tough working conditions.

In automotive applications, 99603-99100 Bearing supports large axles and wheel hubs, providing reliable performance under high stress. Its inch sizing makes it a straightforward fit for American-made vehicles.

For industrial gearboxes, 99603-99100 Bearing’s open design simplifies lubrication and maintenance. The steel cage adds strength, making it suitable for continuous operation in demanding environments.

Where Is 99603-99100 Bearing Used?
You’ll often find 99603-99100 Bearing in mining equipment, where its robust build handles extreme loads. The tapered rollers distribute weight evenly, reducing wear over time.

In agricultural machinery, this bearing supports heavy-duty components like harvesters and tractors. Its standard radial clearance ensures smooth operation even with varying loads.

Built for Heavy-Duty Use: 99603-99100 Bearing
99603-99100 Bearing excels in applications like conveyor systems, where its high dynamic load capacity keeps things running smoothly. The chrome steel rollers resist deformation under pressure.

For paper mill machinery, this bearing’s temperature tolerance ensures reliability in hot, humid conditions. The open seal type allows for easy re-lubrication during maintenance checks.

Automotive vs Aerospace: Applications of 99603-99100 Bearing
In automotive settings, 99603-99100 Bearing handles the heavy loads of truck axles and drivetrains. Its ABEC-1 rating balances precision and cost-effectiveness for these applications.

While not typically used in aerospace, this bearing’s strength makes it suitable for ground support equipment. The inch measurements align well with US-made machinery specs.
