TS (Single Row Tapered Roller Bearings) (Imperial) 467-453A

TS (Single Row Tapered Roller Bearings) (Imperial) 467-453A

The 467-453A is a single-row tapered roller bearing with a 1.875″ bore and 4.25″ outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 36100 lbf radially and 5380 lbf thrust, making it a versatile choice.

Its open design allows for easy lubrication, while the steel cage ensures durability under heavy use. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for applications like automotive axles or industrial gearboxes where combined loads are common.

Weighing 2.8 lb, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe and dependable choice for various mechanical systems.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 467-453A
  • Brand TFL
  • Interchangeable Timken
  • Size 1.875" x 4.25" x 1.0938"
  • Bore Dia 1.875"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 4.25"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1.1542"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.875"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 1.0938"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.03"
  • Cup Backface ToClear Radius 0.03"
  • Cone Frontface Backing Diameter 2.2"
  • Cone Backface Backing Diameter 2.24"
  • Cup Frontface Backing Diameter 3.96"
  • Cup Backface Backing Diameter 3.82"
  • Cage Cone Frontface Clearance 0.08"
  • Cage Cone Backface Clearance 0.07"
  • Effective Center Location -0.28"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 467
  • Cup Part Number 453A
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 455
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 36100 lbf
  • Static Radial Load 37200 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 9370 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 5380 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.8 lb

Features

What Makes 467-453A Bearing Suitable for Heavy-Duty Applications?

467-453A Bearing is constructed with chrome steel rings and rollers, providing excellent resistance to combined loads.
Its dynamic radial load capacity reaches 36,100 lbf, ensuring reliable performance in demanding conditions.
The steel cage maintains proper roller alignment, reducing friction and extending operational life.
With a temperature range of -30° to 110°C, it performs well in various environments.

How Is 467-453A Bearing Engineered for Reliability?

467-453A Bearing features a single-row tapered roller design, optimised for handling combined loads efficiently.
The chrome steel construction enhances durability, while the standard radial clearance allows for smooth operation.
Its dynamic thrust rating of 5,380 lbf ensures consistent performance under heavy loads.
The open design simplifies lubrication, maintaining optimal performance over time.

Built for Durability: 467-453A Bearing

467-453A Bearing’s chrome steel components provide strong resistance to wear and tear.
The tapered roller design distributes loads evenly, reducing stress on individual components.
With a static radial load capacity of 37,200 lbf, it excels in heavy-duty applications.
The steel cage ensures proper roller spacing, enhancing overall stability and longevity.

Steel vs Ceramic Bearings: Strengths of 467-453A Bearing

467-453A Bearing uses chrome steel for both rings and rollers, offering a balance of strength and affordability.
The material choice ensures reliable performance under high dynamic radial loads up to 36,100 lbf.
Its ABEC-1 rating confirms consistent precision, suitable for various industrial applications.
The standard radial clearance provides flexibility for different operating conditions.

Application

Industrial Uses of 467-453A Bearing
The 467-453A Bearing is commonly used in heavy machinery, such as construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. Its chrome steel construction ensures durability in demanding environments.
In automotive applications, 467-453A Bearing fits well in wheel hubs and differential systems, providing reliable performance under both radial and thrust loads. The inch sizing makes it compatible with many North American vehicle models.

What Makes 467-453A Bearing a Preferred Choice?
For industrial conveyors and gearboxes, 467-453A Bearing offers a balance of strength and precision, thanks to its single-row tapered roller design. The open seal type allows for easy lubrication, extending its service life.
In mining equipment, 467-453A Bearing’s robust construction withstands harsh conditions, while its standard radial clearance ensures smooth operation even under heavy loads.

Built for Heavy-Duty Use: 467-453A Bearing
The 467-453A Bearing is ideal for applications like forklifts and cranes, where its dynamic radial load capacity of 36,100 lbf ensures reliable performance. Its steel cage adds extra durability in high-stress scenarios.
In power transmission systems, 467-453A Bearing’s tapered rollers distribute loads evenly, reducing wear and tear. The ABEC-1 rating makes it suitable for general industrial use.

Automotive vs Aerospace: Applications of 467-453A Bearing
In automotive systems, 467-453A Bearing is often found in axles and transmissions, where its combined load handling is crucial. The inch measurements align with many US-made components.
For aerospace ground support equipment, 467-453A Bearing’s temperature range of -30° to 110°C ensures performance in varying conditions, though it’s not typically used in-flight.

Where Is 467-453A Bearing Used?
You’ll often spot 467-453A Bearing in farm machinery like tractors and harvesters, where its tapered rollers manage heavy loads effortlessly. The open design simplifies maintenance in dusty fields.
In manufacturing lines, 467-453A Bearing keeps conveyor belts running smoothly, with its chrome steel rollers resisting wear over time. The standard radial clearance suits most industrial settings.
