Thrust Ball Bearing With Outside Band T-100-37

Thrust Ball Bearing With Outside Band T-100-37

The T-100-37 is a thrust ball bearing with a compact design, measuring 1.94″ in bore diameter and 3.25″ in outer diameter. Made from durable 52100 chrome steel, it handles thrust loads up to 9640 lbf and operates smoothly in temperatures from -30°C to 110°C.

Its 16 steel balls, each 1/2″ in diameter, ensure even load distribution and reliable performance. The bearing requires lubrication for optimal use, making it easy to maintain over time.

With a static thrust load capacity of 35739 lbf, it’s built to withstand heavy-duty applications. Ideal for machinery like pumps or gearboxes where thrust loads are common. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number T-100-37
  • Brand TFL
  • Bore Dia 1.937500"
  • Bore Dia Tolerance +0.001" to +0.003"
  • Inner Dia Housing Washer 1.968750"
  • Outer Dia 3.25"
  • Outer Dia Tolerance -0.015" to +0.015"
  • Width 1.187500"
  • Width Tolerance -0.005" to +0.005"
  • Ball Dia 1/2"
  • Ball Qty 16
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Thrust
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Dynamic Thrust Load 9640 lbf
  • Dynamic Thrust Load(100 RPM) 6350 lbf
  • Dynamic Thrust Load(500 RPM) 3910 lbf
  • Dynamic Thrust Load(1500 RPM) 2810 lbf
  • Static Thrust Load 35739 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.65 kg
Thrust Ball Bearing With Outside Band T-100-37 dimension drawing
Download DWG Download PDF

Features

How Does T-100-37 Bearing Handle Heavy Loads?

T-100-37 Bearing is built with 52100 chrome steel rings and balls, offering robust resistance to high thrust loads.
Its static thrust load capacity reaches 35739 lbf, making it suitable for demanding industrial applications.
The bearing’s design includes 16 balls, each with a diameter of 1/2″, ensuring even load distribution.
With a temperature range of -30° to 110°C, it performs reliably in various operating conditions.

Application

Key Fields for T-100-37 Bearing
T-100-37 Bearing works well in industrial settings, especially for heavy machinery like presses and gearboxes where thrust loads are common. Its inch sizing makes it a good fit for equipment designed to US standards.

In automotive applications, T-100-37 Bearing handles high thrust in components like differential systems or steering mechanisms. The chrome steel construction ensures it can withstand constant pressure and frequent use.

For automation systems, T-100-37 Bearing provides reliable performance in robotic arms and assembly line equipment. The precise tolerances help maintain smooth operation even under repetitive motion.

Medical devices like dental chairs or surgical tables benefit from T-100-37 Bearing’s consistent load handling. The required lubrication ensures long-term reliability in critical healthcare environments.

Around the home, T-100-37 Bearing can be found in sturdy appliances like washing machines or power tools. Its durability makes it a practical choice for everyday mechanical needs.
