Thrust Ball Bearing With Outside Band D20

Thrust Ball Bearing With Outside Band D20

The D20 is a thrust ball bearing with a 1.688-inch bore and 2.969-inch outer diameter, crafted from durable 52100 chrome steel. It handles thrust loads up to 10,300 lbf and operates smoothly at speeds up to 2,400 RPM.

Its robust design includes an outside band for added stability, making it suitable for high-load applications. The bearing requires regular lubrication to maintain optimal performance.

With a temperature range of -30°C to 110°C, it works well in various environments. Compliant with RoHS and REACH standards, it’s a safe and reliable choice.

Ideal for machinery where heavy thrust loads are common, such as industrial equipment or automotive systems. Weighing just 0.81 lbs, it’s both sturdy and easy to handle.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D20
  • Brand TFL
  • Bore Dia 1.688"
  • Bore Dia Tolerance +0.001" to +0.003"
  • Inner Dia Housing Washer 1.719"
  • Outer Dia 2.969"
  • Outer Dia Tolerance -0.015" to +0.015"
  • Width 0.813"
  • Width Tolerance -0.005" to +0.005"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Thrust
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Dynamic Thrust Load 10300 lbf
  • Static Thrust Load 25000 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 2400 rpm
  • Weight 0.81 lbs
Thrust Ball Bearing With Outside Band D20 dimension drawing
Download DWG Download PDF

Features

How Does D20 Bearing Handle Heavy Loads?

D20 Bearing is built with 52100 chrome steel rings and balls, offering robust resistance to high thrust loads.
Its static thrust load capacity reaches 25,000 lbf, making it suitable for heavy-duty applications.
The inch-sized design ensures compatibility with systems requiring precise measurements.
With a temperature range of -30° to 110°C, D20 Bearing performs reliably in varied conditions.

Application

Key Fields for D20 Bearing
D20 Bearing is commonly used in industrial settings, especially for heavy machinery that handles axial loads, like hydraulic pumps and gear reducers. Its inch sizing makes it a good fit for equipment designed to US standards.

Where Is D20 Bearing Used?
In automotive applications, D20 Bearing works well in clutch assemblies and steering systems, where its high static thrust load capacity ensures long-lasting performance. The chrome steel construction adds durability under frequent use.

Built for Heavy-Duty Use: D20 Bearing
For automation systems, D20 Bearing supports robotic arms and conveyor belts, providing reliable thrust load handling. The required lubrication helps maintain smooth operation over time.

Medical vs Industrial: Where D20 Bearing Excels
In medical devices, D20 Bearing’s precise tolerances make it suitable for imaging equipment, while its industrial strength shines in heavy machinery. The temperature range allows for use in varied environments.
