Thin Section Ball Bearings 6804zz

Thin Section Ball Bearings 6804zz

The 6804zz is a slim, shielded ball bearing with a 20mm bore and 32mm outer diameter, designed for radial loads. Its compact 7mm width makes it ideal for tight spaces, while the chrome steel construction ensures durability.

This bearing handles radial loads up to 904 lbf and spins smoothly at speeds up to 25,000 RPM. The stainless steel cage and shielded design help keep dirt out, extending its lifespan.

With a temperature range of -30°C to 110°C, it suits various environments. Regular lubrication is needed for optimal performance.

Weighing just 18g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a reliable choice for small machinery or precision equipment.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6804zz
  • Brand TFL
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.020mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 904 lbf
  • Static Radial Load 554 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 25000 rpm
  • Weight 18 g
  • Price（$） 2
Thin Section Ball Bearings 6804zz dimension drawing
Download DWG Download PDF

Features

Performance Features of 6804zz Bearing

6804zz Bearing features a compact design with dimensions of 20 mm×32 mm×7 mm, making it ideal for space-constrained applications.
Its shielded construction helps protect against contaminants while maintaining smooth operation.

The chrome steel rings and balls provide durability, supporting dynamic radial loads up to 904 lbf.
With a maximum speed of 25,000 rpm, it delivers reliable performance in high-speed scenarios.

6804zz Bearing operates efficiently within a temperature range of -30°C to 110°C.
Its stainless steel cage ensures proper ball alignment, reducing friction and wear.

The ABEC-1 tolerance class and C0 radial clearance offer consistent precision for various industrial uses.
This bearing requires lubrication to maintain optimal performance over time.

Application

Common Applications of 6804zz Bearing
6804zz Bearing is widely used in industrial equipment like conveyor systems and small gearboxes, where its compact design and shielded construction help keep out contaminants. The thin section makes it ideal for space-constrained applications.

In automotive settings, 6804zz Bearing fits well in electric motors and dashboard components, offering smooth rotation with minimal maintenance. Its ABEC-1 tolerance ensures reliable performance for everyday driving conditions.

For home appliances, 6804zz Bearing works efficiently in devices like desk fans and printers, thanks to its lightweight and durable chrome steel construction. The shielded seals also extend its lifespan by reducing dust ingress.

Automation & robotics benefit from 6804zz Bearing’s high-speed capability, making it suitable for robotic arms and precision-guided systems. The stainless steel cage adds stability during repetitive movements.

Medical devices like small pumps often use 6804zz Bearing due to its consistent performance and low noise operation. The metric sizing ensures compatibility with various equipment designs.
