Thin Section Ball Bearings 6706 2rs

Thin Section Ball Bearings 6706 2rs

The 6706 2RS is a slim, sealed ball bearing measuring 30mm by 37mm by 4mm, crafted from chrome steel for durability. It handles radial loads up to 256 lbf and spins smoothly at speeds up to 7000 RPM.

Its sealed design keeps dirt out and grease in, making it low-maintenance. The stainless steel cage ensures reliable performance even under continuous use.

This bearing operates in temperatures from -30°C to 110°C, suitable for various environments. It’s pre-lubricated but may need occasional regreasing for optimal performance.

Ideal for compact applications like small motors or precision instruments where space is limited. Compliant with RoHS and REACH standards, it weighs just 8.3 grams.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6706 2rs
  • Brand TFL
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 37 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 4 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.020mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 256 lbf
  • Static Radial Load 213 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 7000 rpm
  • Weight 8.3 g
  • Price（$） 1.5
Thin Section Ball Bearings 6706 2rs dimension drawing
Download DWG Download PDF

Features

How Does 6706 2rs Bearing Reduce Friction?

6706 2rs Bearing features chrome steel rings and balls, designed to minimise friction during radial load operations.
Its sealed construction helps retain lubrication, ensuring smooth and consistent performance.

The stainless steel cage maintains proper ball alignment, reducing wear and enhancing durability.
With a maximum speed of 7,000 rpm, it offers reliable efficiency in compact applications.

Why Choose 6706 2rs Bearing for Precision Tasks?

6706 2rs Bearing’s ABEC-1 tolerance class ensures consistent precision in radial load applications.
The narrow width of 4 mm makes it ideal for space-constrained installations without sacrificing performance.

Its C0 radial clearance range (0.006mm to 0.020mm) provides stable operation under varying conditions.
The chrome steel construction maintains dimensional stability across its -30°C to 110°C operating range.

Built for Reliability: 6706 2rs Bearing

6706 2rs Bearing’s sealed design protects against contaminants while retaining essential lubrication.
The chrome steel components resist wear, supporting a dynamic radial load of 256 lbf.

Its lightweight construction (8.3 g) doesn’t compromise strength, making it suitable for delicate mechanisms.
The bearing maintains consistent performance within its specified temperature and speed limits.

Application

Common Applications of 6706 2rs Bearing
6706 2rs Bearing is widely used in automation systems, especially in robotic arms where its slim profile and sealed design help maintain precision in tight spaces. The chrome steel construction ensures durability even with frequent movement.

In consumer electronics, 6706 2rs Bearing fits perfectly into devices like printers and small fans, offering smooth rotation with minimal noise. Its lightweight design at just 8.3 grams makes it ideal for portable gadgets.

For medical equipment, 6706 2rs Bearing provides reliable performance in delicate instruments such as lab analyzers, where consistent radial load handling is key. The sealed design also helps keep contaminants out, extending the bearing’s lifespan.
