Stainless Steel Deep Groove Ball Bearings WBB1-8708-2Z

Stainless Steel Deep Groove Ball Bearings WBB1-8708-2Z

The WBB1-8708-2Z is a compact stainless steel deep groove ball bearing, measuring 8mm by 14mm by 4mm. It’s designed for radial loads up to 104 lbf and can handle speeds up to 48,000 RPM.

Its shielded design keeps dirt out while retaining grease, making it low-maintenance. The all-stainless construction ensures good corrosion resistance and durability.

This bearing operates smoothly in temperatures from -30°C to 120°C. It comes pre-lubricated with grease for ready installation.

Ideal for small machinery, medical devices or food processing equipment where hygiene matters. At just 2 grams, it’s lightweight yet robust for its size. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number WBB1-8708-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 14 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 104 lbf
  • Static Radial Load 43 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 48000 rpm
  • Weight 0.002 kg
Stainless Steel Deep Groove Ball Bearings WBB1-8708-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose WBB1-8708-2Z Bearing for Precision Tasks?

WBB1-8708-2Z Bearing is crafted with stainless steel rings and balls, ensuring excellent corrosion resistance.
Its compact size of 8 mm×14 mm×4 mm makes it ideal for applications where space is limited.

The shielded design protects against contaminants, maintaining smooth operation in various environments.
With a maximum speed of 48,000 rpm, it delivers reliable performance in high-speed applications.

WBB1-8708-2Z Bearing’s grease lubrication reduces friction, extending its service life.
Its dynamic radial load capacity of 104 lbf ensures durability under demanding conditions.

Application

Industrial Uses of WBB1-8708-2Z Bearing
WBB1-8708-2Z Bearing is commonly used in small industrial equipment like electric motors and pumps, where its compact size and shielded design help keep contaminants out.
The stainless steel construction makes it resistant to corrosion, ideal for environments with moisture or chemicals.

What Makes WBB1-8708-2Z Bearing a Preferred Choice?
In automotive applications, WBB1-8708-2Z Bearing fits well in components like window regulators and small gearboxes due to its lightweight and durability.
Its high-speed capability ensures smooth operation even in demanding conditions.

Perfect Fit for Automation: WBB1-8708-2Z Bearing
For robotics and automation, WBB1-8708-2Z Bearing offers reliable performance in precise movements, such as in robotic arms or small conveyor systems.
The grease lubrication reduces maintenance needs, making it a hassle-free option for continuous use.

Medical vs Industrial: Where WBB1-8708-2Z Bearing Excels
In medical devices, WBB1-8708-2Z Bearing is often found in handheld instruments, benefiting from its smooth operation and hygiene-friendly stainless steel.
Industrial uses include food processing equipment, where its corrosion resistance meets strict cleanliness standards.
