Single Row Deep Groove Ball Bearings 6212/C3W64

Single Row Deep Groove Ball Bearings 6212/C3W64

The 6212/C3W64 is a single-row deep groove ball bearing with a 60mm bore and 110mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 1178 lbf and operates smoothly at speeds up to 5600 RPM.

Its open design and solid oil lubrication ensure low maintenance, while the chrome steel cage enhances durability. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

With a C3 radial clearance, it accommodates slight misalignments and thermal expansion. This model is interchangeable with SKF bearings, making it a practical choice for replacements.

Ideal for applications like electric motors or pumps where radial loads are common. Weighing 762g, it offers a balance of strength and lightweight design. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6212/C3W64
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 22 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Lubrication Soild Oil
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 1178 lbf
  • Static Radial Load 8138 lbf
  • Max Speed 5600 rpm
  • Weight 762 g
Single Row Deep Groove Ball Bearings 6212/C3W64 dimension drawing
Download DWG Download PDF

Features

Why Choose 6212/C3W64 Bearing for Precision Tasks?

6212/C3W64 Bearing features a single-row deep groove design, ideal for handling radial loads with precision.
Its chrome steel construction ensures durability and resistance to wear in various applications.

The solid oil lubrication system maintains smooth operation, reducing the need for frequent maintenance.
With a dynamic radial load capacity of 1178 lbf, it performs reliably under demanding conditions.

6212/C3W64 Bearing operates efficiently within a temperature range of -30°C to 120°C.
Its ABEC 1 tolerance class guarantees consistent performance for precision tasks.

Application

Industrial Uses of 6212/C3W64 Bearing
This bearing is commonly used in industrial machinery like pumps and electric motors, where its deep groove design handles radial loads efficiently. The C3 clearance ensures reliable performance even with thermal expansion.

In automotive applications, 6212/C3W64 Bearing fits well in wheel hubs and alternators, thanks to its solid oil lubrication reducing maintenance needs. Its chrome steel construction offers durability under varying road conditions.

For automation systems, 6212/C3W64 Bearing works smoothly in conveyor belts and robotic arms, providing consistent rotation. The open seal design allows for easy inspection and re-lubrication when needed.

Where to Use 6212/C3W64 Bearing
You’ll find this bearing in household appliances like washing machines, where its quiet operation and long lifespan are appreciated. The metric sizing makes it compatible with many European-made devices.

In medical equipment, 6212/C3W64 Bearing’s stable performance suits devices like centrifuges, ensuring precise spinning. The wide temperature range allows it to function in various clinical environments.
