Stainless Steel Deep Groove Ball Bearings W 627-2RS1

Stainless Steel Deep Groove Ball Bearings W 627-2RS1

The W 627-2RS1 is a compact stainless steel deep groove ball bearing, measuring 7mm in bore and 22mm in outer diameter, with a width of just 7mm. Its sealed design keeps grease in and dirt out, making it low-maintenance.

This bearing handles radial loads up to 447 lbf and can spin at speeds up to 22,000 RPM, suitable for fast-moving applications. The all-stainless steel construction resists corrosion and lasts longer in harsh conditions.

Ideal for small machinery or electric motors where space is limited. Its P0 tolerance ensures smooth operation, while the CN radial clearance offers reliable performance.

Weighing only 0.012kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a safe choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 627-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 447 lbf
  • Static Radial Load 175 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 22000 rpm
  • Weight 0.012 kg
  • Price（$） 1.74
Stainless Steel Deep Groove Ball Bearings W 627-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 627-2RS1 Bearing for Precision Tasks?

W 627-2RS1 Bearing features a stainless steel construction, ensuring resistance to corrosion and wear.
Its sealed design keeps contaminants out, maintaining smooth operation in various environments.

The dynamic radial load capacity of 447 lbf makes it suitable for precision applications.
With a maximum speed of 22,000 rpm, it delivers reliable performance without compromising efficiency.

W 627-2RS1 Bearing’s compact size (7 mm×22 mm×7 mm) allows for easy integration into small spaces.
Its grease lubrication reduces maintenance needs, making it a practical choice for long-term use.

Application

Common Applications of W 627-2RS1 Bearing
W 627-2RS1 Bearing is widely used in small electric motors, such as those found in household appliances like fans and blenders. Its sealed design keeps out dust and moisture, ensuring long-lasting performance in everyday devices.

In automotive applications, W 627-2RS1 Bearing fits well in components like window regulators and wiper motors. The stainless steel construction resists corrosion, making it reliable even in harsh weather conditions.

For medical devices, W 627-2RS1 Bearing’s compact size and smooth operation make it suitable for handheld instruments. The grease lubrication ensures quiet and efficient performance, which is essential in clinical settings.

In automation systems, W 627-2RS1 Bearing supports precise movements in small robotic arms. Its metric dimensions and radial load capacity make it a versatile choice for light-duty industrial applications.
