Stainless Steel Deep Groove Ball Bearings W 61908-2RS1

Stainless Steel Deep Groove Ball Bearings W 61908-2RS1

The W 61908-2RS1 is a stainless steel deep groove ball bearing measuring 40mm by 62mm by 12mm, designed for radial loads. It handles dynamic loads up to 2675 lbf and operates smoothly at speeds up to 6700 RPM.

Its sealed construction keeps grease in and dirt out, making it low-maintenance and durable. The all-stainless steel design resists corrosion, ideal for humid or wet environments.

This bearing works well in temperatures from -30°C to 120°C, suitable for various industrial uses. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing just 0.11kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it’s a safe choice for many applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61908-2RS1
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 12 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 2675 lbf
  • Static Radial Load 2203 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 0.11 kg
  • Price（$） 42.47
Stainless Steel Deep Groove Ball Bearings W 61908-2RS1 dimension drawing
Download DWG Download PDF

Features

Why Choose W 61908-2RS1 Bearing for Precision Tasks?

W 61908-2RS1 Bearing is crafted with stainless steel rings and balls, ensuring excellent corrosion resistance and durability.
Its sealed design protects against contaminants, making it ideal for precision applications.
The bearing handles dynamic radial loads up to 2675 lbf, providing reliable performance under stress.
With a maximum speed of 6,700 rpm, it balances efficiency and longevity.

Application

Industrial Uses of W 61908-2RS1 Bearing
W 61908-2RS1 Bearing is commonly used in industrial settings, such as conveyor systems and pumps, where its sealed design helps keep contaminants out. The stainless steel construction ensures durability even in harsh environments.

How Does W 61908-2RS1 Bearing Improve Performance?
In automotive applications like electric motors, W 61908-2RS1 Bearing provides reliable radial load support. Its grease lubrication reduces friction, extending the lifespan of moving parts.

Perfect Fit for Automation: W 61908-2RS1 Bearing
This bearing works well in robotic arms and automated machinery, where precision and low maintenance are key. The metric sizing makes it easy to integrate into various designs.

Medical vs Industrial: Where W 61908-2RS1 Bearing Excels
While suitable for industrial gear, W 61908-2RS1 Bearing also meets the hygiene needs of medical devices like lab equipment. Its stainless steel material resists corrosion and frequent cleaning.

Essential Roles of W 61908-2RS1 Bearing
In household appliances like washing machines, W 61908-2RS1 Bearing ensures smooth operation. The sealed design protects against dust and moisture, ideal for everyday use.
