Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/W64F

Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/W64F

The W 61906-2RS1/W64F is a compact stainless steel deep groove ball bearing, measuring 30mm by 47mm by 9mm. It’s designed for radial loads and handles up to 1403 lbf, with a maximum speed of 19,000 RPM.

Its sealed construction keeps out dirt and moisture, while the solid oil lubrication ensures smooth operation. The stainless steel rings and balls offer good corrosion resistance, making it durable in harsh conditions.

This bearing is interchangeable with SKF models, ideal for replacements in machinery or small equipment. It works well in temperatures from -30°C to 120°C, suitable for various industrial applications.

Weighing just 0.043kg, it’s lightweight yet sturdy. Compliant with REACH standards, it’s a reliable choice for maintenance or new installations.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61906-2RS1/W64F
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 9 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1403 lbf
  • Static Radial Load 1124 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 19000 rpm
  • Weight 0.043 kg
  • Price（$） 25.52
Stainless Steel Deep Groove Ball Bearings W 61906-2RS1/W64F dimension drawing
Download DWG Download PDF

Features

How Does W 61906-2RS1/W64F Bearing Reduce Friction?

W 61906-2RS1/W64F Bearing features stainless steel rings and balls, designed to minimise friction during operation.
Its sealed construction keeps contaminants out, ensuring smooth performance even in challenging environments.

The solid oil lubrication reduces maintenance needs while enhancing the bearing’s efficiency.
With a maximum speed of 19,000 rpm, it delivers reliable performance for high-speed applications.

W 61906-2RS1/W64F Bearing’s radial load capacity of 1403 lbf makes it suitable for various industrial uses.
Its compact size (30 mm×47 mm×9 mm) allows for easy integration into different machinery setups.

Application

Common Applications of W 61906-2RS1/W64F Bearing
W 61906-2RS1/W64F Bearing works well in industrial settings, especially for conveyor systems and small machinery where its sealed design keeps dirt out. The stainless steel construction helps it resist corrosion in damp environments.

In automotive applications, W 61906-2RS1/W64F Bearing fits nicely into electric motors and pumps, offering smooth rotation with minimal maintenance. Its solid oil lubrication ensures long service life even under constant use.

For home appliances like washing machines, W 61906-2RS1/W64F Bearing handles radial loads quietly and efficiently. The compact size makes it ideal for space-saving designs without sacrificing performance.

Medical devices benefit from W 61906-2RS1/W64F Bearing’s precision and cleanliness, suitable for lab equipment and small diagnostic tools. The sealed feature prevents contamination in sensitive environments.

In robotics, W 61906-2RS1/W64F Bearing supports lightweight arms and joints, providing reliable movement with low friction. Its high-speed capability suits repetitive tasks in automated systems.
