Stainless Steel Deep Groove Ball Bearings W 61808-2Z

Stainless Steel Deep Groove Ball Bearings W 61808-2Z

The W 61808-2Z is a stainless steel deep groove ball bearing with a 40mm bore and 52mm outer diameter, measuring just 7mm wide. Its compact size makes it suitable for tight spaces while maintaining strength.

This shielded bearing handles radial loads up to 877 lbf and can spin at speeds up to 13,000 RPM. The stainless steel construction offers good corrosion resistance for demanding environments.

Its single-row design provides smooth operation, and the grease lubrication ensures long service life. The bearing works in temperatures from -30°C to 120°C.

Ideal for applications like small motors or food processing equipment where hygiene matters. Compliant with RoHS and REACH standards, it weighs only 0.03kg for easy handling.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61808-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 877 lbf
  • Static Radial Load 843 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 13000 rpm
  • Weight 0.03 kg
Stainless Steel Deep Groove Ball Bearings W 61808-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose W 61808-2Z Bearing for Precision Tasks?

W 61808-2Z Bearing features stainless steel construction, offering excellent resistance to corrosion and wear.
Its shielded design helps keep contaminants out while retaining lubrication for smooth operation.

The bearing’s dynamic radial load capacity of 877 lbf ensures reliable performance in various applications.
With a maximum speed of 13,000 rpm, it delivers both precision and efficiency.

W 61808-2Z Bearing’s compact size (40 mm×52 mm×7 mm) makes it suitable for space-constrained installations.
Its P0 tolerance class ensures consistent performance in precision tasks.

Application

Industrial Uses of W 61808-2Z Bearing
W 61808-2Z Bearing is commonly used in industrial settings, such as conveyor systems and small machinery, where its shielded design helps keep contaminants out. The stainless steel construction ensures it can handle moderate radial loads without corrosion concerns.

What Makes W 61808-2Z Bearing a Preferred Choice?
In automotive applications, W 61808-2Z Bearing fits well in electric motors and small gearboxes due to its compact size and reliable performance. The grease lubrication allows for smooth operation even at higher speeds.

Perfect Fit for Automation: W 61808-2Z Bearing
For automation equipment like robotic arms, W 61808-2Z Bearing offers precise movement thanks to its single-row design. The metric dimensions make it easy to integrate into various European and Asian machinery.

Medical vs Industrial: Where W 61808-2Z Bearing Excels
In medical devices, W 61808-2Z Bearing’s stainless steel material is ideal for sterile environments, while in industrial tools, its durability shines. The P0 tolerance ensures consistent performance across different uses.

Light-Duty vs Heavy-Duty: Best Uses for W 61808-2Z Bearing
W 61808-2Z Bearing works well in light-duty applications like printers or small fans, where its low weight is an advantage. For heavier tasks, its dynamic load capacity still provides reliable support.
