Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/W64

Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/W64

The W 6006-2RS1/W64 is a stainless steel deep groove ball bearing with a 30mm bore and 55mm outer diameter, measuring 13mm wide. Its sealed design keeps dirt out and solid oil lubrication ensures smooth operation.

This bearing handles radial loads up to 2563 lbf and spins at speeds up to 17,000 RPM. Made entirely of stainless steel (except the chrome steel cage), it resists corrosion and lasts longer in harsh conditions.

The ABEC 1 precision rating makes it suitable for general industrial use. It works in temperatures from -30°C to 120°C and weighs just 0.1kg.

Ideal for food processing equipment or marine applications where moisture resistance matters. Interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6006-2RS1/W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 55 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 13 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 2563 lbf
  • Static Radial Load 1832 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 17000 rpm
  • Weight 0.1 kg
  • Price（$） 29.03
Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/W64 dimension drawing
Download DWG Download PDF

Features

Why Choose W 6006-2RS1/W64 Bearing for Precision Tasks?

W 6006-2RS1/W64 Bearing is crafted with stainless steel rings and balls, ensuring excellent corrosion resistance and durability.
Its sealed design keeps contaminants out, making it ideal for environments where cleanliness is crucial.

The solid oil lubrication reduces maintenance needs while providing consistent performance.
With a maximum speed of 17,000 rpm, it delivers smooth operation in high-speed applications.

W 6006-2RS1/W64 Bearing’s ABEC 1 tolerance ensures reliable precision for radial load tasks.
Its dynamic radial load capacity of 2563 lbf makes it suitable for demanding industrial uses.

Application

Where Is W 6006-2RS1/W64 Bearing Used?
W 6006-2RS1/W64 Bearing is commonly used in industrial equipment like pumps and electric motors, where its sealed design helps keep contaminants out. The stainless steel construction also makes it suitable for wet or corrosive environments.

In automotive applications, W 6006-2RS1/W64 Bearing works well in components like alternators and water pumps, thanks to its reliable radial load capacity. The solid oil lubrication ensures smooth performance even under continuous use.

For home appliances, W 6006-2RS1/W64 Bearing can be found in washing machines and fans, where its quiet operation and durability are appreciated. The metric sizing makes it easy to replace in a variety of household devices.

Automation systems benefit from W 6006-2RS1/W64 Bearing’s consistent performance in robotic arms and conveyor belts. Its ABEC 1 tolerance ensures adequate precision for most automated tasks.
