Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/VP311

Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/VP311

The W 6006-2RS1/VP311 is a stainless steel deep groove ball bearing, measuring 30mm by 55mm by 13mm. It handles radial loads up to 2563 lbf and runs smoothly at speeds up to 8000 RPM.

Its sealed design keeps grease in and dirt out, making it low-maintenance. The all-stainless construction resists corrosion, ideal for damp or harsh environments.

This model works in temperatures from -30°C to 120°C and is interchangeable with SKF bearings. Perfect for food processing equipment or marine applications where rust resistance matters.

Weighing just 0.11kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6006-2RS1/VP311
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 55 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 13 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 2563 lbf
  • Static Radial Load 1832 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8000 rpm
  • Weight 0.11 kg
  • Price（$） 21.05
Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/VP311 dimension drawing
Download DWG Download PDF

Features

How Does W 6006-2RS1/VP311 Bearing Reduce Friction?

W 6006-2RS1/VP311 Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its sealed design retains lubrication, reducing wear and extending maintenance intervals.

The single-row construction of W 6006-2RS1/VP311 Bearing provides reliable radial load support up to 2563 lbf.
With a maximum speed of 8,000 rpm, it delivers consistent performance in various applications.

W 6006-2RS1/VP311 Bearing operates efficiently in temperatures from -30° to 120°C, making it versatile.
Its stainless steel materials resist corrosion, ensuring durability in challenging environments.

The grease lubrication in W 6006-2RS1/VP311 Bearing ensures long-lasting smooth operation.
Its compact size (30 mm×55 mm×13 mm) makes it suitable for space-constrained installations.

Application

Practical Applications of W 6006-2RS1/VP311 Bearing
W 6006-2RS1/VP311 Bearing is commonly used in industrial fans and pumps, where its sealed design keeps contaminants out while handling radial loads efficiently. The stainless steel construction also makes it suitable for humid or corrosive environments.

In automotive applications, W 6006-2RS1/VP311 Bearing works well in electric motors and alternators, providing reliable performance with minimal maintenance. Its compact size and metric dimensions ensure easy integration into various vehicle systems.

For food processing equipment, W 6006-2RS1/VP311 Bearing’s grease lubrication and sealed features help maintain hygiene standards. The stainless steel materials resist rust, even with frequent washdowns.

In home appliances like washing machines, W 6006-2RS1/VP311 Bearing offers quiet operation and long service life. The sealed design prevents dust and moisture from affecting performance over time.

Robotic arms often use W 6006-2RS1/VP311 Bearing for smooth, precise movement. Its balanced load capacity and durability make it a dependable choice for automated systems.
