Stainless Steel Deep Groove Ball Bearings D/W RW168-2Z

Stainless Steel Deep Groove Ball Bearings D/W RW168-2Z

The D/W RW168-2Z is a compact stainless steel deep groove ball bearing, measuring just 0.25″ by 0.375″ by 0.15618″. Its shielded design keeps dirt out while maintaining smooth rotation.

With a dynamic radial load capacity of 48 lbf, it handles moderate forces well and spins up to 60,000 RPM. The all-stainless construction resists corrosion and works in temperatures from -30°C to 120°C.

Pre-greased for easy use, this bearing fits applications where cleanliness matters, like food processing or medical equipment. It’s interchangeable with SKF models for straightforward replacements.

Weighing only 0.0006kg, it’s ideal for lightweight mechanisms. Compliant with RoHS and REACH standards for safe operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W RW168-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.25"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.375"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.15618"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 48 lbf
  • Static Radial Load 20 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 60000 rpm
  • Weight 0.0006 kg
Stainless Steel Deep Groove Ball Bearings D/W RW168-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose D/W RW168-2Z Bearing for Precision Tasks?

D/W RW168-2Z Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its shielded design protects against contaminants, ensuring smooth operation in various environments.

With a dynamic radial load capacity of 48 lbf, it handles demanding radial applications effectively.
The precision tolerances and shielded seals enhance its reliability and longevity.

D/W RW168-2Z Bearing operates at speeds up to 60,000 rpm, making it suitable for high-speed tasks.
Its compact size and lightweight design allow for easy integration into small assemblies.

Application

Common Applications of D/W RW168-2Z Bearing
D/W RW168-2Z Bearing is a great fit for small industrial equipment like precision instruments and miniature motors, where its stainless steel construction offers good corrosion resistance. The shielded design helps keep contaminants out, extending its lifespan in dusty environments.

In automotive applications, D/W RW168-2Z Bearing works well in small electric motors or sensors, thanks to its compact inch sizing. Its grease lubrication ensures smooth operation even in tight spaces.

For medical devices, D/W RW168-2Z Bearing’s stainless steel build makes it suitable for sterilisation-prone areas like dental tools. The P0 tolerance class ensures reliable performance in critical settings.

In consumer electronics, D/W RW168-2Z Bearing can be found in devices like small fans or printers, where its low weight and quiet operation are appreciated. The shielded seals help maintain performance over time.

Automation systems benefit from D/W RW168-2Z Bearing’s high-speed capability, making it useful in robotic arms or small conveyor mechanisms. Its radial load handling suits light-duty repetitive motions.
