Stainless Steel Deep Groove Ball Bearings D/W R6-2Z

Stainless Steel Deep Groove Ball Bearings D/W R6-2Z

The D/W R6-2Z is a stainless steel deep groove ball bearing, measuring 0.375″ in bore and 0.875″ in outer diameter, with a compact width of 0.28118″. Its shielded design keeps grease in and contaminants out, making it low-maintenance.

This bearing handles radial loads up to 555 lbf and spins at speeds up to 36,000 RPM, suitable for fast-moving applications. The all-stainless construction resists corrosion and works in temperatures from -30°C to 120°C.

Its precision tolerances ensure smooth operation, while the grease lubrication simplifies upkeep. Ideal for small machinery, medical devices, or food processing equipment where hygiene matters.

Weighing just 0.011kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R6-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.375"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.875"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.28118"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 555 lbf
  • Static Radial Load 252 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 36000 rpm
  • Weight 0.011 kg
Stainless Steel Deep Groove Ball Bearings D/W R6-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R6-2Z Bearing for Precision Tasks?

D/W R6-2Z Bearing features stainless steel construction, offering excellent resistance to corrosion and wear.
Its shielded design protects against contaminants, ensuring smooth operation in various environments.

With a dynamic radial load capacity of 555 lbf, D/W R6-2Z Bearing handles demanding applications with ease.
The precision tolerances and grease lubrication contribute to its reliable performance.

D/W R6-2Z Bearing operates at speeds up to 36,000 rpm, making it suitable for high-speed applications.
Its compact size and lightweight design allow for easy integration into different systems.

The all-stainless steel components ensure durability and a long service life.
D/W R6-2Z Bearing is ideal for applications requiring precision and reliability.

Application

Common Applications of D/W R6-2Z Bearing
D/W R6-2Z Bearing is widely used in industrial equipment, such as small conveyor systems and electric motors, where its shielded design helps keep out contaminants. The stainless steel construction ensures it performs well in humid or corrosive environments.

Where Is D/W R6-2Z Bearing Used?
In automotive applications, D/W R6-2Z Bearing can be found in components like alternators and small gearboxes, providing reliable radial load support. Its inch sizing makes it a good fit for many North American and Asian vehicle models.

Ideal for Precision: D/W R6-2Z Bearing
For medical devices like dental tools or lab equipment, D/W R6-2Z Bearing offers smooth operation and resistance to frequent sterilisation. The grease lubrication ensures quiet performance, which is essential in sensitive environments.

Automotive vs Industrial: Applications of D/W R6-2Z Bearing
In consumer electronics, D/W R6-2Z Bearing is often used in small fans or printers, where its compact size and durability are key. The shielded seals help extend its lifespan by preventing dust buildup.
