Stainless Steel Deep Groove Ball Bearings D/W R0

Stainless Steel Deep Groove Ball Bearings D/W R0

The D/W R0 is a compact stainless steel deep groove ball bearing, measuring just 0.04689″ by 0.15618″ by 0.06252″. Its open design and single-row construction make it easy to handle and install.

This bearing supports radial loads up to 14 lbf and can reach speeds of 140,000 RPM, ideal for small, fast-moving applications. The all-stainless steel build ensures corrosion resistance and durability.

With a temperature range of -30°C to 120°C, it works well in varied environments. Its lightweight design, at only 0.0001kg, makes it suitable for precision instruments.

Interchangeable with SKF bearings, it’s a reliable choice for replacements in delicate machinery or medical devices. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W R0
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.04689"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.15618"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.06252"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 14 lbf
  • Static Radial Load 4 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 140000 rpm
  • Weight 0.0001 kg
Stainless Steel Deep Groove Ball Bearings D/W R0 dimension drawing
Download DWG Download PDF

Features

Why Choose D/W R0 Bearing for Precision Tasks?

D/W R0 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its compact size of 0.04689″×0.15618″×0.06252″ makes it ideal for precision applications where space is limited.
The open design allows for easy lubrication, ensuring smooth operation even at high speeds up to 140,000 rpm.
With a dynamic radial load capacity of 14 lbf, it provides reliable performance in demanding conditions.

Application

Common Applications of D/W R0 Bearing
D/W R0 Bearing is widely used in small industrial equipment, such as precision instruments and miniature motors, where its stainless steel construction offers good corrosion resistance. Its compact size makes it ideal for tight spaces.

In the automotive sector, D/W R0 Bearing can be found in small components like fuel pumps or sensors, providing reliable performance under radial loads. The inch sizing ensures compatibility with various international designs.

For medical devices, D/W R0 Bearing’s open design and stainless steel materials suit applications like dental tools or lab equipment, where hygiene and durability are key. The P0 tolerance class ensures consistent operation.

In consumer electronics, D/W R0 Bearing is often used in devices like small fans or printers, where its low weight and smooth operation enhance performance. The high-speed capability makes it a versatile choice.
