Single Row Deep Groove Ball Bearings 63001-2RS1

The 63001-2RS1 is a compact single-row deep groove ball bearing, measuring 12mm by 28mm by 12mm. Made from chrome steel, it’s built to handle radial loads up to 1140 lbf and spins smoothly at speeds up to 17,000 RPM.

Its sealed design keeps grease in and dirt out, reducing maintenance needs. The stainless steel cage adds durability, making it a reliable choice for long-term use.

This bearing works well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF models, offering a cost-effective replacement option.

Ideal for small motors, pumps, or appliances where space is limited but performance matters. Weighing just 0.029kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number 63001-2RS1
Brand TFL
Interchangeable SKF
System of Measurement Metric
For Load Direction Radial
Construction Single Row
Bearing Type Ball
Seal Type Sealed
Tolerance Class P6
Radial Clearance Trade No CN
Bore Dia 12 mm
Bore Dia Tolerance -0.007mm to 0
Outer Dia 28 mm
Outer Dia Tolerance -0.008mm to 0
Width 12 mm
Width Tolerance -0.12mm to 0
Ring Material Chrome Steel
Ball Material Chrome Steel
Cage Material Stainless Steel
Lubrication Grease
REACH Compliant
Temperature Range -30° to 120 °C
Dynamic Radial Load 1140 lbf
Static Radial Load 531 lbf
Max Speed 17000 rpm
Weight 0.029 kg
price（$） 5.067

Single Row Deep Groove Ball Bearings 63001-2RS1 dimension drawing

Download DWG Download PDF

Features

Why Choose 63001-2RS1 Bearing for Precision Tasks?

63001-2RS1 Bearing features sealed construction, protecting against dust and moisture for consistent performance.

Its chrome steel rings and balls ensure durability, even under radial loads up to 1140 lbf.

The stainless steel cage maintains ball alignment, reducing friction and extending service life.

With a maximum speed of 17,000 rpm, it delivers smooth operation in precision applications.

Application

Common Applications of 63001-2RS1 Bearing
63001-2RS1 Bearing is widely used in industrial equipment like small electric motors and pumps, where its sealed design keeps contaminants out. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 63001-2RS1 Bearing fits well in components such as alternators and cooling fans, providing reliable radial load support. Its metric sizing makes it compatible with various vehicle models.

For home appliances, 63001-2RS1 Bearing works smoothly in devices like washing machines and power tools. The grease lubrication helps maintain quiet operation over long periods.

What Makes 63001-2RS1 Bearing a Preferred Choice?
63001-2RS1 Bearing offers a balance of performance and affordability, making it popular in consumer electronics like printers. Its sealed design reduces maintenance needs.

The stainless steel cage in 63001-2RS1 Bearing enhances its lifespan in high-speed applications like small fans. The temperature range suits both indoor and outdoor use.

Built for Versatility: 63001-2RS1 Bearing
63001-2RS1 Bearing is a go-to choice for light-duty machinery, such as conveyor systems in packaging lines. Its compact size fits tight spaces without compromising performance.

In automation setups, 63001-2RS1 Bearing supports precise movements in robotic arms. The P6 tolerance class ensures consistent accuracy for repetitive tasks.
