Stainless Steel Deep Groove Ball Bearings D/W ER1038-2ZS

Stainless Steel Deep Groove Ball Bearings D/W ER1038-2ZS

The D/W ER1038-2ZS is a stainless steel deep groove ball bearing, measuring 0.375″ in bore and 0.625″ in outer diameter. Its compact width of 0.15618″ makes it suitable for tight spaces.

This single-row bearing handles radial loads up to 110 lbf and spins smoothly at speeds up to 43,000 RPM. The shielded design keeps grease in and contaminants out for reliable performance.

Made entirely of stainless steel, it resists corrosion and works in temperatures from -30°C to 120°C. The grease lubrication ensures smooth operation with minimal maintenance.

Ideal for small machinery or instruments where durability and cleanliness matter. Weighing just 0.0026kg, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number D/W ER1038-2ZS
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 0.375"
  • Bore Dia Tolerance -0.00019" to 0.00019"
  • Outer Dia 0.625"
  • Outer Dia Tolerance -0.0007" to -0.00031"
  • Width 0.15618"
  • Width Tolerance -0.005" to 0"
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 110 lbf
  • Static Radial Load 49 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 43000 rpm
  • Weight 0.0026 kg
Stainless Steel Deep Groove Ball Bearings D/W ER1038-2ZS dimension drawing
Download DWG Download PDF

Features

Why Choose D/W ER1038-2ZS Bearing for Precision Tasks?

D/W ER1038-2ZS Bearing features stainless steel construction, offering excellent resistance to corrosion and wear.
Its shielded design helps keep contaminants out, ensuring smooth operation in various environments.

With a dynamic radial load capacity of 110 lbf, it handles demanding radial loads efficiently.
The precision-engineered components ensure consistent performance, even at high speeds up to 43,000 rpm.

D/W ER1038-2ZS Bearing’s compact size makes it ideal for applications where space is limited.
Its grease lubrication reduces maintenance needs, providing long-lasting reliability.

Application

Common Applications of D/W ER1038-2ZS Bearing
D/W ER1038-2ZS Bearing is widely used in small electric motors, such as those found in household appliances like blenders and fans. Its stainless steel construction ensures resistance to corrosion, making it suitable for damp environments.

In automation systems, D/W ER1038-2ZS Bearing provides smooth operation in components like robotic arms and conveyor belts. The shielded design helps keep contaminants out, extending the bearing’s lifespan.

For medical devices, D/W ER1038-2ZS Bearing offers reliable performance in equipment like dental tools and lab instruments. Its compact size and precision make it ideal for applications where space is limited.

In consumer electronics, D/W ER1038-2ZS Bearing is often found in printers and small gadgets. The grease lubrication ensures quiet operation, which is essential for noise-sensitive environments.
