Single Row Deep Groove Ball Bearings 6013-ZJEM

Single Row Deep Groove Ball Bearings 6013-ZJEM

The 6013-ZJEM is a single-row deep groove ball bearing with a 65mm bore and 100mm outer diameter, crafted from sturdy chrome steel for reliable performance. Its shielded design helps keep dirt out while maintaining smooth operation.

This model handles radial loads up to 6857 lbf and spins comfortably at speeds reaching 6700 RPM. The chrome steel cage ensures durability, making it suitable for continuous use in various conditions.

With a compact width of just 18mm, it fits neatly into tight spaces without sacrificing strength. The bearing operates well in temperatures from -30°C to 120°C, adapting to different environments.

Ideal for machinery requiring consistent radial load support, such as electric motors or conveyor systems. Compliant with RoHS and REACH standards, it’s a safe and practical choice for industrial applications. Weighing 430g, it offers a good balance of strength and manageability.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6013-ZJEM
  • Brand TFL
  • Interchangeable SKF
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 18 mm
  • Width Tolerance -0.150mm to 0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • ROHS Compliant
  • REACH Compliant
  • Temperature Range -30°to 120 °C
  • Dynamic Radial Load 6857 lbf
  • Static Radial Load 5665 lbf
  • Max Speed 6700 rpm
  • Weight 430 g
  • price（$） 13.257
Single Row Deep Groove Ball Bearings 6013-ZJEM dimension drawing
Download DWG Download PDF

Features

How Does 6013-ZJEM Bearing Reduce Friction?

6013-ZJEM Bearing features a shielded design, keeping contaminants out while maintaining smooth operation.
Its chrome steel construction ensures durability and reduces friction for efficient radial load handling.

The single row deep groove design allows for high-speed performance, up to 6,700 rpm.
With a dynamic radial load capacity of 6857 lbf, it delivers reliable performance in various applications.

6013-ZJEM Bearing operates in temperatures from -30°C to 120°C, suitable for diverse environments.
Its shielded seal type helps retain lubrication, reducing maintenance needs over time.

Application

Industrial Uses of 6013-ZJEM Bearing
6013-ZJEM Bearing is commonly used in industrial machinery like pumps and electric motors, where its shielded design helps keep contaminants out. The chrome steel construction ensures it can handle radial loads efficiently in demanding environments.

What Makes 6013-ZJEM Bearing a Preferred Choice?
In automotive applications, 6013-ZJEM Bearing fits well in wheel hubs and transmission systems due to its balanced load capacity. The ABEC 1 tolerance makes it reliable for standard precision needs without overcomplicating maintenance.

Perfect Fit for Automation: 6013-ZJEM Bearing
For automated systems, 6013-ZJEM Bearing works smoothly in conveyor belts and robotic arms. Its moderate speed rating and sturdy build make it a dependable choice for continuous operation.

Medical vs Industrial: Where 6013-ZJEM Bearing Excels
While 6013-ZJEM Bearing isn’t typically used in medical devices, it shines in industrial settings like packaging machines. The consistent performance and easy interchangeability with SKF models add to its practicality.
