Spherical Roller Thrust Bearings 294/1060 EF

Spherical Roller Thrust Bearings 294/1060 EF

The 294/1060 EF is a large spherical roller thrust bearing with a 1060mm bore and 1770mm outer diameter, built to handle heavy combined loads. It supports dynamic thrust loads up to 7.5 million lbf and operates at speeds up to 240 RPM.

Made from durable steel, its single-row design includes a steel cage for reliable performance. The bearing requires regular lubrication and works in temperatures from -30°C to 100°C.

Its spherical rollers help manage misalignment, making it suitable for demanding industrial applications like heavy machinery or mining equipment. The design includes a 15mm chamfer for easier installation.

Weighing 4280kg, this robust bearing is interchangeable with SKF models. Compliant with RoHS and REACH standards, it’s a dependable choice for high-load scenarios.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 294/1060 EF
  • Brand TFL
  • Interchangeable SKF
  • Size 1060 mm x 1770 mm x 426 mm
  • Bore Dia 1060 mm
  • Bore Dia Tolerance -0.125 to 0
  • Outer Dia 1770 mm
  • Outer Dia Tolerance -0.2 to 0
  • Width 426 mm
  • Outside Diameter(d1) 1615 mm
  • Shoulder Diameter Outer Ring (D1) 1349 mm
  • Height Shaft Washer Cage(B1) 412 mm
  • Height Housing Washer(C) 207 mm
  • Distance From Shaft Washer End Side Face To Pressure Point(s) 610 mm
  • Chamfer Dimension Shaft Washer(r1,2) 15 mm
  • System of Measurement Metric
  • Roller Bearing Type Spherical
  • Bearing Type Roller
  • For Load Direction Combined
  • Construction Single Row
  • Roller Material Steel
  • Cage Material Steel
  • Dynamic Thrust Load 7508619 lbf
  • Static Thrust Load 35070195 lbf
  • Max Speed 240 rpm
  • Lubrication Required
  • Temperature Range -30 to 100 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 4280 kg
  • Height Tolerance -0.4 to 0
  • Price（$） 8425.8

Features

Performance Features of 294/1060 EF Bearing

294/1060 EF Bearing is built for combined load applications, with a dynamic thrust load capacity of 7,508,619 lbf.
Its spherical roller design ensures smooth operation even under heavy loads.

The steel rollers and cage provide durability, making it suitable for demanding industrial environments.
With a maximum speed of 240 rpm, it balances performance and reliability.

294/1060 EF Bearing operates in temperatures from -30 to 100°C, adapting to various working conditions.
Its large size (1060 mm x 1770 mm x 426 mm) is designed for heavy-duty machinery.

The bearing requires lubrication, ensuring long service life and reduced wear.
Its robust construction makes it a reliable choice for high-load applications.

Application

Industrial Uses of 294/1060 EF Bearing
294/1060 EF Bearing is commonly used in heavy machinery like mining equipment and large presses, where its spherical roller design handles combined loads with ease. The steel construction ensures durability even in demanding industrial environments.

What Makes 294/1060 EF Bearing a Preferred Choice?
With a bore diameter of 1060 mm, 294/1060 EF Bearing fits perfectly in large-scale applications such as wind turbines and hydroelectric generators. Its high dynamic thrust load capacity makes it reliable for continuous operation.

Built for Heavy-Duty Use: 294/1060 EF Bearing
294/1060 EF Bearing excels in applications like ship propulsion systems, where its ability to handle both axial and radial loads is crucial. The steel cage provides added strength, ensuring long service life.

Automotive vs Aerospace: Applications of 294/1060 EF Bearing
In automotive testing rigs, 294/1060 EF Bearing supports high loads during durability tests. For aerospace, its precision and robustness make it suitable for ground support equipment like aircraft jacks.

Essential Roles of 294/1060 EF Bearing
294/1060 EF Bearing is vital in steel mills, where it withstands extreme loads and temperatures. The metric sizing ensures compatibility with a wide range of industrial machinery across different regions.
