Snap Ring Groove Ball Bearings 6310-RSNR

Snap Ring Groove Ball Bearings 6310-RSNR

The 6310-RSNR is a sealed snap ring groove ball bearing with a 50mm bore and 110mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 13938 lbf and operates smoothly at speeds up to 6000 RPM.

Its snap ring design ensures secure fitting, while the sealed construction keeps out dust and debris for longer life. The bearing performs reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for machinery like pumps or electric motors where radial loads and secure mounting are key.

Weighing 1050g, it’s sturdy yet manageable for its size. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6310-RSNR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 27 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 116.6 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 13938 lbf
  • Static Radial Load 861 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6000 rpm
  • Weight 1050 g
  • Price（$） 29.2
Snap Ring Groove Ball Bearings 6310-RSNR dimension drawing
Download DWG Download PDF

Features

How Does 6310-RSNR Bearing Ensure Smooth Operation?

6310-RSNR Bearing features a sealed design, keeping contaminants out and maintaining smooth performance.
Its chrome steel construction provides excellent resistance to wear, ensuring long-lasting reliability.

The snap ring fitted on the outer ring simplifies installation and enhances stability.
With a dynamic radial load capacity of 13938 lbf, it handles heavy-duty applications effortlessly.

Designed for speeds up to 6,000 rpm, it balances efficiency and durability.
The ABEC 1 tolerance ensures consistent performance in various operating conditions.

Application

Industrial Uses of 6310-RSNR Bearing
6310-RSNR Bearing works well in conveyor systems, where its snap ring design ensures secure placement during continuous operation. The sealed construction keeps contaminants out, extending service life in dusty environments.

Where Is 6310-RSNR Bearing Used?
You’ll often spot 6310-RSNR Bearing in electric motors, thanks to its balanced radial load capacity and smooth rotation. Its chrome steel build handles moderate speeds reliably, making it a go-to for industrial gearboxes.

Optimized for Performance: 6310-RSNR Bearing
In agricultural machinery like harvesters, 6310-RSNR Bearing stands up to vibration and variable loads. The snap ring groove simplifies installation, saving time during equipment maintenance.

Automotive vs Aerospace: Applications of 6310-RSNR Bearing
While 6310-RSNR Bearing fits truck wheel hubs nicely, its precision isn’t wasted on aircraft auxiliary units either. The temperature range covers most ground and low-altitude flight needs.

Perfect Fit for Automation: 6310-RSNR Bearing
Robotic arms benefit from 6310-RSNR Bearing’s consistent torque and sealed protection against workshop debris. Its 50mm bore suits compact servo motor designs perfectly.
