Snap Ring Groove Ball Bearings 6309-2RS1NR/C3 GJN

Snap Ring Groove Ball Bearings 6309-2RS1NR/C3 GJN

The 6309-2RS1NR/C3 GJN is a snap ring groove ball bearing with a 45mm bore and 100mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 11915 lbf and operates smoothly at speeds up to 6700 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs. The snap ring feature ensures secure fitting, making installation straightforward.

This bearing works well in temperatures from -30°C to 120°C, suitable for various industrial environments. It’s interchangeable with SKF models, offering a reliable replacement option.

Weighing 811g, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for most applications. Ideal for machinery where radial loads and secure mounting are key.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6309-2RS1NR/C3 GJN
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 25 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 106.5 mm
  • Width Of Snap Ring 2.46 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 11915 lbf
  • Static Radial Load 7194 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 6700 rpm
  • Weight 811 g
  • Price（$） 22.6
Snap Ring Groove Ball Bearings 6309-2RS1NR/C3 GJN dimension drawing
Download DWG Download PDF

Features

How Is 6309-2RS1NR/C3 GJN Bearing Engineered for Reliability?

6309-2RS1NR/C3 GJN Bearing features a sealed design, protecting against dust and moisture for consistent performance.
The chrome steel construction ensures durability, even under high radial loads up to 11915 lbf.

Its snap ring outer ring provides secure mounting, reducing the risk of misalignment during operation.
With a maximum speed of 6,700 rpm, it balances efficiency and longevity in various applications.

The C3 radial clearance allows for thermal expansion, making it suitable for a wide temperature range.
This design ensures smooth operation from -30°C to 120°C, adapting to different working conditions.

Application

Industrial Uses of 6309-2RS1NR/C3 GJN Bearing
6309-2RS1NR/C3 GJN Bearing is commonly used in conveyor systems and industrial fans, where its sealed design keeps contaminants out. The snap ring feature ensures secure mounting, reducing maintenance needs in dusty environments.

Where Is 6309-2RS1NR/C3 GJN Bearing Used?
In automotive applications, 6309-2RS1NR/C3 GJN Bearing fits well in electric motors and pumps, thanks to its radial load capacity. The C3 clearance allows for thermal expansion, making it reliable under varying temperatures.

Built for Heavy-Duty Use: 6309-2RS1NR/C3 GJN Bearing
This bearing handles high loads in agricultural machinery, such as tractors and harvesters. Its chrome steel construction offers durability, even in harsh outdoor conditions.

Automotive vs Industrial: Applications of 6309-2RS1NR/C3 GJN Bearing
While 6309-2RS1NR/C3 GJN Bearing excels in car transmissions, it’s equally effective in factory equipment like gearboxes. The sealed design works well in both oily and dusty settings.

Perfect Fit for Automation: 6309-2RS1NR/C3 GJN Bearing
In robotic arms, 6309-2RS1NR/C3 GJN Bearing provides smooth rotation with minimal friction. The snap ring ensures stability during repetitive movements, ideal for precision tasks.
