Snap Ring Groove Ball Bearings 6305-2RS1NR/C3GJN

Snap Ring Groove Ball Bearings 6305-2RS1NR/C3GJN

The 6305-2RS1NR/C3GJN is a sealed snap ring groove ball bearing with a 25mm bore and 62mm outer diameter, made from sturdy chrome steel. It handles radial loads up to 4631 lbf and can spin at speeds up to 11000 RPM.

Its sealed design keeps out dirt and moisture, while the snap ring ensures secure fitting. The bearing operates smoothly in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads are common.

Weighing 232g, it’s a compact yet durable option. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6305-2RS1NR/C3GJN
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 17 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 67.7 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No C3
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 4631 lbf
  • Static Radial Load 254 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 232 g
  • Price（$） 5.33
Snap Ring Groove Ball Bearings 6305-2RS1NR/C3GJN dimension drawing
Download DWG Download PDF

Features

Performance Features of 6305-2RS1NR/C3GJN Bearing

6305-2RS1NR/C3GJN Bearing is designed with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 4631 lbf, ensuring reliable performance in various applications.

The sealed design of 6305-2RS1NR/C3GJN Bearing protects against dust and moisture, extending its service life.
With a maximum speed of 11,000 rpm, it delivers smooth and efficient operation.

6305-2RS1NR/C3GJN Bearing features a snap ring on the outer ring, simplifying installation and positioning.
Its C3 radial clearance provides optimal performance under varying thermal conditions.

The chrome steel cage ensures proper ball alignment, reducing wear and enhancing durability.
Operating within a temperature range of -30°C to 120°C, it adapts to diverse environments.

Application

Common Applications of 6305-2RS1NR/C3GJN Bearing
In industrial settings, 6305-2RS1NR/C3GJN Bearing is widely used in conveyor systems and electric motors, thanks to its sealed design that keeps contaminants out. The snap ring feature ensures easy installation and secure positioning in housings.

How Does 6305-2RS1NR/C3GJN Bearing Improve Performance?
For automotive applications like alternators and water pumps, 6305-2RS1NR/C3GJN Bearing offers reliable radial load support. Its C3 clearance allows for slight thermal expansion, making it suitable for varying temperatures.

Built for Heavy-Duty Use: 6305-2RS1NR/C3GJN Bearing
In agricultural machinery, 6305-2RS1NR/C3GJN Bearing handles tough conditions with its chrome steel construction. The sealed design also protects against dust and moisture, extending service life.

Automotive vs Industrial: Where 6305-2RS1NR/C3GJN Bearing Excels
While 6305-2RS1NR/C3GJN Bearing performs well in car transmissions, it’s equally effective in industrial gearboxes. The snap ring simplifies mounting, saving time during assembly.

Perfect Fit for Automation: 6305-2RS1NR/C3GJN Bearing
In robotic arms and automated systems, 6305-2RS1NR/C3GJN Bearing ensures smooth rotation with minimal maintenance. Its sealed design reduces the need for frequent lubrication.
