Snap Ring Groove Ball Bearings 6304-2RS1NRJEM

Snap Ring Groove Ball Bearings 6304-2RS1NRJEM

The 6304-2RS1NRJEM is a sealed snap ring groove ball bearing with a 20mm bore and 52mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 3574 lbf and spins smoothly at speeds up to 14,000 RPM.

Its sealed design keeps dirt out and grease in, while the snap ring ensures secure mounting. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or pumps where radial loads and secure positioning are needed.

Weighing just 144g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6304-2RS1NRJEM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 15 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 57.9 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 3574 lbf
  • Static Radial Load 1765 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 14000 rpm
  • Weight 144 g
  • Price（$） 5
Snap Ring Groove Ball Bearings 6304-2RS1NRJEM dimension drawing
Download DWG Download PDF

Features

Why Choose 6304-2RS1NRJEM Bearing for Precision Tasks?

6304-2RS1NRJEM Bearing features a sealed design, protecting against dust and moisture for consistent performance.
Its chrome steel construction ensures durability and resistance to wear in radial load applications.

The snap ring groove on the outer ring provides secure mounting, reducing the risk of misalignment.
With a dynamic radial load capacity of 3574 lbf, it handles demanding conditions efficiently.

Operating at speeds up to 14,000 rpm, 6304-2RS1NRJEM Bearing maintains smooth and reliable motion.
Its temperature range of -30°C to 120°C makes it suitable for various industrial environments.

Application

Common Applications of 6304-2RS1NRJEM Bearing
In industrial settings, 6304-2RS1NRJEM Bearing is commonly used in conveyor systems and electric motors, where its sealed design protects against dust and debris. The snap ring feature ensures secure mounting, reducing maintenance needs.

Where Is 6304-2RS1NRJEM Bearing Used?
You’ll often find 6304-2RS1NRJEM Bearing in automotive applications like alternators and water pumps, thanks to its reliable radial load handling. Its compact size and sealed construction make it ideal for tight spaces.

Built for Heavy-Duty Use: 6304-2RS1NRJEM Bearing
This bearing excels in machinery like agricultural equipment, where durability is key. The chrome steel construction ensures long-lasting performance even in tough conditions.

Automotive vs Industrial: Applications of 6304-2RS1NRJEM Bearing
In cars, 6304-2RS1NRJEM Bearing supports smooth operation in components like fans and pulleys. For factories, it’s a go-to for pumps and gearboxes, balancing load and speed.

Perfect Fit for Automation: 6304-2RS1NRJEM Bearing
Robotic arms and packaging machines benefit from 6304-2RS1NRJEM Bearing’s precision and sealed design. It handles repetitive motions effortlessly, ensuring consistent performance.
