Thrust Ball Bearing With Outside Band T-100-42

Thrust Ball Bearing With Outside Band T-100-42

The T-100-42 is a thrust ball bearing measuring 2.5″×4″×1.25″, made from sturdy 52100 chrome steel for durability. It handles thrust loads up to 10900 lbf, with performance varying by speed, making it versatile for different applications.

Its outside band design provides stability, while the 20 steel balls ensure smooth operation. Regular lubrication is needed to maintain performance, especially in temperatures ranging from -30°C to 110°C.

This bearing is ideal for heavy-duty machinery where high thrust loads are common. Its inch measurements and robust build make it a reliable choice for industrial equipment. Compliant with RoHS and REACH standards, it’s both safe and dependable.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number T-100-42
  • Brand TFL
  • Bore Dia 2.5"
  • Bore Dia Tolerance +0.001" to +0.003"
  • Inner Dia Housing Washer 2.531250"
  • Outer Dia 4"
  • Outer Dia Tolerance -0.015" to +0.015"
  • Width 1.25"
  • Width Tolerance -0.005" to +0.005"
  • Ball Dia 1/2"
  • Ball Qty 20
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Thrust
  • Ring Material 52100 Chrome Steel
  • Ball Material 52100 Chrome Steel
  • Dynamic Thrust Load 10900 lbf
  • Dynamic Thrust Load(100 RPM) 7180 lbf
  • Dynamic Thrust Load(500 RPM) 4425 lbf
  • Dynamic Thrust Load(1500 RPM) 3175 lbf
  • Static Thrust Load 44674 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.97 kg
Thrust Ball Bearing With Outside Band T-100-42 dimension drawing
Download DWG Download PDF

Features

How Is T-100-42 Bearing Engineered for Reliability?

T-100-42 Bearing features 52100 chrome steel rings and balls, ensuring durability under high thrust loads.
Its dynamic thrust load capacity reaches 10,900 lbf, making it suitable for demanding applications.

The bearing’s design includes 20 precision balls, each with a diameter of 1/2″, for smooth operation.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

T-100-42 Bearing requires lubrication, which helps maintain its efficiency and longevity.
Its inch-based measurements and tolerances ensure compatibility with a wide range of machinery.

Application

Key Fields for T-100-42 Bearing
T-100-42 Bearing works well in industrial settings like heavy machinery, where its robust design handles high thrust loads with ease. The inch sizing makes it a good fit for equipment designed to imperial standards.

In automotive applications, T-100-42 Bearing is often used in gearboxes and differential systems, providing reliable performance under pressure. Its chrome steel construction ensures longevity even in demanding conditions.

For automation systems, T-100-42 Bearing supports precise movements in robotic arms and conveyor belts. The consistent load capacity makes it a dependable choice for repetitive tasks.

In household appliances like washing machines, T-100-42 Bearing helps reduce friction in rotating parts. Its durability ensures smooth operation over long periods.

Medical devices benefit from T-100-42 Bearing’s precision, particularly in imaging equipment where stability is key. The temperature range allows for use in various clinical environments.
