Snap Ring Groove Ball Bearings 6206-ZNRQ66 HT51

Snap Ring Groove Ball Bearings 6206-ZNRQ66 HT51

The 6206-ZNRQ66 HT51 is a shielded snap ring groove ball bearing with a 30mm bore and 62mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 4384 lbf and spins smoothly at speeds up to 11000 RPM.

Its snap ring design keeps it securely in place, while the shielded construction protects against dust and debris. The bearing operates reliably in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for applications like electric motors or conveyor systems where secure mounting is needed.

Weighing just 199g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6206-ZNRQ66 HT51
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 16 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 67.7 mm
  • Width Of Snap Ring 1.7 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Shielded
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 4384 lbf
  • Static Radial Load 254 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 199 g
  • Price（$） 5.71
Snap Ring Groove Ball Bearings 6206-ZNRQ66 HT51 dimension drawing
Download DWG Download PDF

Features

How Does 6206-ZNRQ66 HT51 Bearing Reduce Friction?

6206-ZNRQ66 HT51 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design helps keep contaminants out, maintaining performance over time.
The snap ring groove on the outer ring provides secure positioning, reducing unnecessary movement.
With a maximum speed of 11,000 rpm, it offers reliable efficiency for various applications.

Application

Where Is 6206-ZNRQ66 HT51 Bearing Used?
In industrial settings, 6206-ZNRQ66 HT51 Bearing is commonly fitted into conveyor systems and electric motors, where its shielded design helps keep out dust and debris.
The snap ring feature ensures secure placement in machinery, reducing the risk of slippage during operation.

How Does 6206-ZNRQ66 HT51 Bearing Support High-Speed Operations?
This bearing handles radial loads efficiently in automotive applications like alternators and pumps, thanks to its chrome steel construction.
Its ABEC 1 tolerance ensures reliable performance even at speeds up to 11,000 rpm, making it suitable for demanding environments.

Perfect Fit for Automation: 6206-ZNRQ66 HT51 Bearing
In robotic arms and automated assembly lines, 6206-ZNRQ66 HT51 Bearing offers smooth movement with minimal maintenance.
The shielded seals protect against contaminants, extending the bearing’s lifespan in high-use scenarios.

Industrial vs Automotive: Performance of 6206-ZNRQ66 HT51 Bearing
While industrial machines benefit from its snap ring for stability, automotive systems rely on its high-speed capability.
The metric sizing makes it versatile for various equipment, from gearboxes to power tools.

Why Choose 6206-ZNRQ66 HT51 Bearing for Medical Devices?
In lab equipment like centrifuges, 6206-ZNRQ66 HT51 Bearing provides quiet and precise rotation.
Its temperature resistance up to 120°C ensures consistent performance in sterilisation processes.
