Snap Ring Groove Ball Bearings 6006 N

Snap Ring Groove Ball Bearings 6006 N

The 6006 N is a snap ring groove ball bearing with a 30mm bore and 55mm outer diameter, crafted from sturdy chrome steel. It manages radial loads up to 3102 lbf and operates smoothly at speeds up to 17,000 RPM.

Its open design and stainless steel cage ensure durability, while the snap ring groove on the outer ring provides secure positioning. The bearing performs reliably in temperatures ranging from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. It’s well-suited for applications like electric motors or pumps where secure mounting is needed.

Weighing just 0.12kg, it’s lightweight yet robust. Compliant with REACH standards, it’s a safe and dependable option for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6006 N
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 55 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 13 mm
  • Width Tolerance -0.12mm to 0
  • Outside Diameter Of Snap Ring 55 mm
  • Width Of Snap Ring 1.35 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Open
  • Locating Feature Bearing Outer Ring Snap Ring Groove
  • Tolerance Class P6
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 3102 lbf
  • Static Radial Load 1866 lbf
  • Temperature Range -30° to 120 °C
  • REACH Compliant
  • Max Speed 17000 rpm
  • Weight 0.12 kg
Snap Ring Groove Ball Bearings 6006 N dimension drawing
Download DWG Download PDF

Features

How Does 6006 N Bearing Reduce Friction?

6006 N Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
The stainless steel cage maintains proper ball alignment, enhancing efficiency and reducing wear.
With a dynamic radial load capacity of 3102 lbf, it handles demanding applications effortlessly.
Its snap ring groove design simplifies installation, making it a practical choice for various setups.

What Ensures Smooth Operation in 6006 N Bearing?

6006 N Bearing’s precision-engineered chrome steel components provide consistent performance under radial loads.
The open design allows for easy lubrication, ensuring smooth rotation even at high speeds.
Its snap ring groove offers secure mounting, reducing vibrations and noise.
With a maximum speed of 17,000 rpm, it delivers reliable operation in diverse conditions.

Built for Reliability: 6006 N Bearing

6006 N Bearing is crafted with durable chrome steel, offering long-lasting performance in radial applications.
The stainless steel cage ensures stability, preventing misalignment and extending service life.
Its snap ring groove design enhances mounting security, making it ideal for compact spaces.
Operating within a temperature range of -30° to 120°C, it adapts to various environments.

Application

Industrial Uses of 6006 N Bearing
6006 N Bearing is commonly used in machine tools and conveyor systems, where its snap ring groove ensures secure mounting and easy installation. The open design allows for efficient lubrication, making it suitable for continuous operation in industrial settings.

Where Is 6006 N Bearing Used?
You’ll often find 6006 N Bearing in automotive applications like electric motors and pumps, where its radial load capacity and durability are key. The metric sizing makes it a versatile choice for various vehicle models.

Perfect Fit for Automation: 6006 N Bearing
6006 N Bearing works well in robotic arms and automated assembly lines, thanks to its precise tolerance class and smooth operation. The chrome steel construction ensures long-lasting performance even in high-speed scenarios.

Medical vs Industrial: Where 6006 N Bearing Excels
In medical devices like lab equipment, 6006 N Bearing offers reliable performance due to its stainless steel cage and clean operation. For industrial uses, its snap ring groove provides stability in heavy-duty machinery.
