Snap Ring Groove Ball Bearings 6002-2RSNRJEM

Snap Ring Groove Ball Bearings 6002-2RSNRJEM

The 6002-2RSNRJEM is a compact snap ring groove ball bearing, measuring 15mm in bore and 32mm in outer diameter, with a width of 9mm. Made from durable chrome steel, it handles radial loads up to 1259 lbf and spins smoothly at speeds up to 23,000 RPM.

Its sealed design keeps dirt out and grease in, reducing maintenance needs. The snap ring on the outer ring ensures a secure fit, making installation straightforward.

This bearing operates well in temperatures from -30°C to 120°C, suitable for various environments. It’s interchangeable with SKF bearings, offering a reliable replacement option.

Weighing just 30g, it’s lightweight yet sturdy. Ideal for applications like small motors or machinery where space is limited and a secure fit is needed. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6002-2RSNRJEM
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 15 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 36.7 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1259 lbf
  • Static Radial Load 641 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 23000 rpm
  • Weight 30 g
  • Price（$） 5.79
Snap Ring Groove Ball Bearings 6002-2RSNRJEM dimension drawing
Download DWG Download PDF

Features

How Does 6002-2RSNRJEM Bearing Reduce Friction?

6002-2RSNRJEM Bearing features a sealed design with chrome steel components, ensuring smooth operation and reduced friction.
Its single-row construction and snap ring outer ring provide stability, making it ideal for radial load applications.
The bearing can handle speeds up to 23,000 rpm while maintaining consistent performance.
With a temperature range of -30° to 120°C, it adapts well to various working conditions.

Application

Common Applications of 6002-2RSNRJEM Bearing
In industrial machinery, 6002-2RSNRJEM Bearing is a go-to for radial load support, especially in conveyor systems and small motors. Its sealed design keeps contaminants out, ensuring longer service life in dusty environments.

How Does 6002-2RSNRJEM Bearing Improve Performance?
For automotive applications like electric window mechanisms, 6002-2RSNRJEM Bearing offers smooth rotation and low noise. The snap ring feature simplifies installation, making it a favourite for compact designs.

Ideal for Precision: 6002-2RSNRJEM Bearing
In medical devices such as dental drills, 6002-2RSNRJEM Bearing provides reliable performance due to its chrome steel construction. The sealed design also helps maintain hygiene in sensitive environments.

Automotive vs Industrial: Where 6002-2RSNRJEM Bearing Excels
While commonly used in car alternators, 6002-2RSNRJEM Bearing also shines in industrial fans. Its ABEC 1 tolerance ensures consistent performance across both high and low-speed applications.

Perfect Fit for Automation: 6002-2RSNRJEM Bearing
In robotic arms, 6002-2RSNRJEM Bearing’s compact size and sealed design make it ideal for precise movements. The snap ring ensures secure mounting, even in high-vibration setups.
