Snap Ring Groove Ball Bearings 6002-2RSHNR

Snap Ring Groove Ball Bearings 6002-2RSHNR

The 6002-2RSHNR is a compact snap ring groove ball bearing with a 15mm bore and 32mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 1259 lbf and can spin at speeds up to 23,000 RPM.

Its sealed design keeps dirt out and grease in, while the snap ring ensures a secure fit in housings. The bearing operates smoothly in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for applications like electric motors or small machinery where space is limited.

Weighing just 30g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6002-2RSHNR
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 15 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 32 mm
  • Outer Dia Tolerance -0.011mm to 0
  • Width 9 mm
  • Width Tolerance -0.120mm to 0
  • Outside Diameter Of Snap Ring 36.7 mm
  • Width Of Snap Ring 1.12 mm
  • System of Measurement Metric
  • For Load Direction Radial
  • Construction Single Row
  • Bearing Type Ball
  • Seal Type Sealed
  • Locating Feature Bearing Outer Ring Snap Ring (fitted)
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 1259 lbf
  • Static Radial Load 641 lbf
  • Temperature Range -30°to 120 °C
  • ROHS Compliant
  • REACH Compliant
  • Max Speed 23000 rpm
  • Weight 30 g
  • Price（$） 5.14
Snap Ring Groove Ball Bearings 6002-2RSHNR dimension drawing
Download DWG Download PDF

Features

How Does 6002-2RSHNR Bearing Reduce Friction?

6002-2RSHNR Bearing features a sealed design with chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its single-row construction and snap ring groove provide stability, reducing unnecessary movement and wear.
The ABEC 1 tolerance class ensures consistent performance, even at high speeds up to 23,000 rpm.
With a dynamic radial load capacity of 1259 lbf, it offers reliable performance in various applications.

Application

Common Applications of 6002-2RSHNR Bearing
6002-2RSHNR Bearing is widely used in industrial equipment like conveyor belts and small motors, where its sealed design keeps contaminants out. The snap ring feature ensures secure mounting in compact spaces.

In automotive applications, 6002-2RSHNR Bearing fits well in electric window mechanisms and cooling fans, thanks to its radial load capacity. The chrome steel construction offers durability in high-temperature environments.

For home appliances, 6002-2RSHNR Bearing works smoothly in washing machine pumps and vacuum cleaner motors. Its sealed design prevents dust ingress, extending the lifespan of these devices.

Where Is 6002-2RSHNR Bearing Used?
6002-2RSHNR Bearing is a reliable choice for office printers and scanners, where low noise and smooth operation are key. The snap ring simplifies installation in tight spaces.

In robotics, 6002-2RSHNR Bearing supports joint movements and lightweight arms, ensuring precise motion. The sealed construction protects against dust and debris in dynamic environments.

Built for Versatility: 6002-2RSHNR Bearing
6002-2RSHNR Bearing handles radial loads efficiently in power tools like drills and sanders. Its compact size and snap ring make it easy to integrate into various designs.

For medical devices, 6002-2RSHNR Bearing provides quiet operation in dental handpieces and lab equipment. The sealed design maintains hygiene by preventing lubricant leakage.

Automotive vs Industrial: Applications of 6002-2RSHNR Bearing
In automotive alternators, 6002-2RSHNR Bearing ensures reliable performance under constant rotation. Its sealed design protects against engine contaminants.

For industrial fans, 6002-2RSHNR Bearing offers long service life with minimal maintenance. The snap ring feature allows quick replacement in hard-to-reach areas.
